Cooper Lighting Solutions Fail-Safe FVS4 Instructions D'installation

IB519080EN
Installation Instructions – FVS4/FVS8
Instructions d'installation – FVS4/FVS8
Instrucciones de instalación – FVS4/FVS8
WARNING
Risk of Fire/Shock. If not qualified, consult an
electrician.
WARNING
Risk of Electric Shock. Disconnect power at fuse or
circuit breaker before installing or servicing.
IMPORTANTe: Read carefully before installing fixture. Retain for future reference.
GENERALe: Upon receipt of fixture thoroughly inspect for any freight damage, which should be brought to the attention
of the delivery carrier. Compare the catalog description listed on the packing slip with the fixture label on the housing to
assure you have received the correct merchandise.
SAFETYe: This fixture must be wired in accordance with the National Electrical Code and applicable local codes and
ordinances. Proper grounding is required to insure personal safety. Carefully observe grounding procedure. All work
should be done by an electrician.
1. Slide lens toward one end and lift out.
Figure 1.
N otee: These instructions do not claim to cover all
details or variations in the equipment, procedure,
or process described, nor to provide directions
for meeting every possible contingency during
installation, operation or maintenance. When
additional information is desired to satisfy a
problem not covered sufficiently for user's purpose,
please contact your nearest representative. Design
specifications and dimensions are subject to
change without notice.
2. Remove reflector by removing (2) speed nuts.
Disconnect orange QD ports between the LED boards
and the drivers.
Figure 2.
Brand Logo
reversed out of
black
INS # INS #
