8.2.2 Wireless M-Bus repeater AMR (battery)

The battery repeater can repeat all Wireless M-Bus frame, provided they conform to EN13757 standards and that the transmission mode is T1
mode.
The battery repeater is configured to listen to a daily 4 min and 10 seconds , by default
Under these conditions, we can use a few dozens of transmitters per repeaters maintaining a long life
Battery type
Li-SOCl2
Li-SOCl2

9. Wireless M-Bus Receiver AMR

The Wireless M-Bus Receiver AMR (Automatic Meter Reading) from Adeunis RF is a ready-to-use system allowing to receive consumption data
from Wireless M-Bus transmitters AMR or Wireless M-Bus repeater AMR.
This receiver can acquire Wireless M-Bus frames and transit them to any collection device and / or operating data with a RS232 or RS485 serial
port.
At first switch on, by default, the AMR RECEIVER is set to : T1 «Other».
Serial port parameters : 115.2kbps / 8bits / no parity
The Product is ready to use without any configuration needed.

9.1. Technical specifications

9.1.1 Products

Name
Wireless M-Bus receiver AMR (RS232)
Wireless M-Bus receiver AMR (RS485)
Wireless M-Bus receiver AMR (USB)

9.1.2 General characteristics

Parameters
Serial port data rate
Power supply
Operating temperature
Dimensions
Case
Standards

9.1.3 Radio characteristics

Module type
Wireless M-Bus 14dBm (25mW)

9.2. Implementation of Wireless M-Bus receiver AMR

9.2.1 Wireless M-Bus receiver AMR RS232

By default, the receiver is configured for T1 mode. Simply connect power and serial port and all T1 Wireless M-Bus frames will be transmitted on
the RS232 serial link (frame format is described in the User Module Guide Wireless M-Bus is available on the website Adeunis RF
).
rf.com
Mode Daily repetition
T1 250 sec (4mn and 10 sec)
T1 180 sec (3mn)
Reference
ARF7922BA
ARF79222CA
ARF7922EA
Value
115.2kbps (8N1)
Main through provided power supply
-40°C / +85°C
145 x 100 x 40
IP 65
EN 300-220, EN 301-489, EN 60950, EN 13757-3 et EN 13757-4
RF power Sensitivity (if RX Adeunis RF)
-110 dBm mode T1
Autonomy Reference
8 years ARF7924AA
10 years on demand
Firmware version
V1.0
V1.0
V1.0
data rate
100 kbps
Range
-
