3 3 . . T T e e c c h h n n i i c c a a l l d d a a t t a a
Four-stroke motor
Displacement
Max. speed
Fuel
Tank capacity
Oil quantity
Spark plug
LPA sound pressure level
LWA sound power level
Max. pumping height
Max. pressure
Max. pumping rate
Max. suction height
Suction and pressure connection
4 4 . . R R e e s s i i s s t t a a n n c c e e
For continuous operation, the maximum temperature of
the liquid being pumped should not exceed +35°C.
Liquids which are flammable or explosive, or which
generate gas, must not be delivered with this pump. The
pumping of aggressive liquids (acids, alkalis, silo
seepage etc.) as well as liquids with abrasive
substances (sand) must likewise be avoided.
5 5 . . I I n n t t e e n n d d e e d d u u s s e e
A A r r e e a a s s o o f f a a p p p p l l i i c c a a t t i i o o n n
To be used for watering parks, vegetable patches and
gardens.
To be used for the operation of sprinklers.
To be used, with a preliminary filter, for the removal of
water from ponds, brooks, water butts, rainwater
cisterns and fountains.
P P u u m m p p i i n n g g m m e e d d i i u u m m
For the pumping of clear water (fresh water),
rainwater or light suds/service water.
6 6 . . O O p p e e r r a a t t i i n n g g i i n n s s t t r r u u c c t t i i o o n n s s
As a basic principle, we recommend the use of a
preliminary filter and a suction set with suction hose,
suction strainer and return valve, in order to prevent
16.01.2006 16:36 Uhr
long priming periods and unnecessary damage to the
pump as a result of stones and solid foreign bodies.
4,35 PS / 3,2 kW
163 cm 3
7 7 . . B B e e f f o o r r e e p p u u t t t t i i n n g g t t h h e e m m a a c c h h i i n n e e i i n n t t o o o o p p e e r r a a t t i i o o n n
-1
3600 min
The pump is self-priming. Before putting into
Regular unleaded petrol
operation for the first time, the pump must be
3,6 l
filled, using the filling nozzle, up to overflowing
with pumping liquid.
0,6 l
NGK BPR5ES
C C o o n n n n e e c c t t i i o o n n o o f f a a s s u u c c t t i i o o n n p p i i p p e e : :
Position the suction pipe so that it rises from the
86 dB(A)
water withdrawal point to the pump. Avoid
102 dB(A)
positioning the suction pipe higher than the pump,
as this would delay the escape of air bubbles from
30 m
the suction pipe and impede the priming process.
3,0 bar
Suction and pressure pipes are to be mounted in
such a way that they do not exert any mechanical
21960 l/h
pressure on the pump.
6 m
The suction valve should be located at a depth in
the water which is sufficient to avoid dry running of
2"
the pump when the water level falls.
A leaky suction pipe impedes the suction of water
due to air intake.
Avoid the suction of foreign bodies (sand etc.). A
preliminary filter is to be used if necessary.
8 8 . . S S t t a a r r t t i i n n g g u u p p
Fill with approx. 0.6 l of engine oil (15W40) (see
"Changing the oil").
Place the pump on a level and secure surface.
The pressure pipe must be connected to the
pump's pressure pipe connection (3) either directly
or via a threaded nipple.
Mount the suction pipe so that it is ready for
operation.
Fill the pump with water at the filling nozzle (2).
Important: If you operate the pump with the supplied
reducers, the pump output is reduced.
T T o o s s t t a a r r t t u u p p : : ( ( s s e e e e F F i i g g . . 1 1 ) )
1. Fill the tank with petrol (1).
2. Open the petrol cock (8).
3. Position the throttle control (10) in the center.
4. In the case of a cold start, close the choke lever
(9).
5. Set the ON/OFF switch (6) to the "ON" position.
6. Pull forcefully on the cable pull-starter (7).
7. After a running time of approx. 1 minute, re-open
the choke lever (9).
8. In the case of a warm motor, you can leave
