SITE PREPARATION

Opening Dimensions

INTEGRATED MODELS
635 mm
OPENING
DEPTH
654 mm
FOR OUTDOOR
MODEL
TOP VIEW
H W
OPENING OPENING WIDTH
HEIGHT
SIDE VIEW FRONT VIEW
*89 mm finished returns will be visible and should be finished to match cabinetry—
114 mm for outdoor model.
19
mm
TYPICAL
89 mm 89 mm
FINISHED FINISHED FILLER
RETURN* RETURN*
W W
FRAMELESS CABINETRY FRAMED CABINETRY
OPENING DIMENSIONS
COLUMN AND TALL W
457 mm Column 457 mm 2134 mm
610 mm Column 610 mm 2134 mm
762 mm Column and Tall 762 mm 2134 mm
914 mm Column and Tall 914 mm 2134 mm
DRAWER W
610 mm Drawer 610 mm
762 mm Drawer 762 mm
914 mm Drawer 914 mm
The depth of each wine storage model is 610 mm. Allow for
panel thickness when planning the finished opening depth.
A minimum 89 mm finished return is required on all sides of
the opening—114 mm for outdoor model. Framed cabinets
will require additional finished filler material behind the face
frame for a proper installation. Refer to the illustration.

DUAL INSTALLATION

When installing two units side by side in a dual installa-
tion, the opening width is the width of the two units added
together. A dual installation kit will be required for this instal-
lation. If a dual installation kit is not specified, a minimum
51 mm filler strip is required between units.
Dual installation kits are available through an authorized
Sub-Zero dealer.

Electrical

Installation must comply with all applicable electrical codes
and be properly grounded (earthed).
The electrical supply must be located within the shaded
H
area shown in the illustration and chart below. A separate
circuit, servicing only this appliance is required. Model
ICBID-24RO is designed and safe for use in outdoor
applications.
H
For indoor models, a ground fault circuit
IMPORTANT NOTE:
876 mm
interrupter (GFCI) is not recommended and may cause inter-
876 mm
ruption of operation.
876 mm
For the outdoor model, a ground fault circuit interrupter
(GFCI) is required to reduce the risk of electrical shock.
This appliance is equipped with an appliance inlet type
device. The appliance inlet is located at the bottom rear of
the appliance. When replacing the power cord verify the
replacement cord is rated HO5VV-F3G1.0 or equivalent to
ensure safe operation.
ELECTRICAL REQUIREMENTS
Power Supply
Circuit Breaker
Receptacle
ELECTRICAL SUPPLY LOCATION
WIDTH
457 mm Models
610 mm Models
762 mm Models
914 mm Models
LEFT SIDE
OF OPENING
114 mm
A
108
E
mm
FLOOR
6 mm
FRONT VIEW
Electrical supply location
CAUTION
The outlet must be checked by a qualified electrician to
be sure that it is wired with the correct polarity. Verify
that the outlet is properly grounded (earthed).
WARNING
Do not use an extension cord, two-prong adapter or
remove the power cord ground prong.
Electrical
Shock
Hazard
Plug power cord directly into a properly
grounded (earthed) outlet.
Do not defeat the grounding (earthing)
nature of the plug.
Do not use adapter or extension cord.
220-240 V AC, 50/60 Hz
Failure to follow these instructions could
cause serious injury or death.
10 amp
grounding-type (earthed) See installation instructions
A
152 mm
241 mm
318 mm
394 mm
|
