• 1
INSTALLATION
By means of a straight spanner
nscrew the nozzle
with the corresponding one.
- Replace them with injectors for the
gas to be used, as shown in the gas
characteristics table (1.5);
- Thoroughly engage the key on the
injector.
- Strongly block the injectors.
Do not go beyond this limit; you
could to damage the product.
- Re-fit the burner heads, caps and pan
supports.
Every time you change the type
of gas used, tick the appropriate box
on the label in the wallet. Refer to
the "corresponding gas connection"
paragraph
3) Set the retarders on the taps:
ceux-ci sont situés sous les manettes
(1.4.2).
A
- Adjust each tap in turn
- Remove the knobs
washers by pulling them upwards.
B
U
and substitute it
C
, and sealing
A
— Changing from natural gas to
L
butane/propane:
- Insert a flat-tipped screwdriver C into
the hole in the control panel and turn
the by-pass screw
correct minimum setting, turn the screw
clockwise.
As regards G30 gas burners, the
by-pass screw must be tightened
completely.
The setting of the minimum must
always be correct and the flame must
always remain on even if the position is
changed from maximum to minimum.
— Changing from butane/propane to
natural gas:
- Insert a flat-tipped screwdriver C into
the hole in the control panel and turn
the by-pass screw
correct minimum setting, turn the screw
counterclockwise.
The setting of the minimum must
always be correct and the flame must
always remain on even if the position is
changed from maximum to minimum.
1•5 - GAS PROPERTIES :
The table (1.5) shows the installation
of the injectors on your appliance
depending on the gas used. Each
number is marked on the injector.
10
(1.4.5), and, for
F
(1.4.5), and, for
F
