Slave Function
05 06
SOCOMEC - Ref. : 875 510A
523 20B
524 20C
525 20D
526 20E
Zone size: 15 words or F hexadecimal
Example:
Configuration of a 4-wired unbalanced
network (4 LNB) for Diris number 5.
High-order Low-order
address address
02 00
Diris Ap reply: Identical to message
sent
1 OUT1 impulse duration:
1: 100 ms
2: 200 ms
3: 300 ms
4: 400 ms
5: 500 ms
6: 600 ms
7: 700 ms
8: 800 ms
9: 900 ms
1 OUT 2 allocation:
0: kWh +
1: kvarh +
2: kVA
3: kWh –4: kvarh -
1 OUT 2 impulse value:
0: 0.1 kWh/kvarh/kVA
1: 1 kWh/kvarh/kVA
2: 10 kWh/kvarh/kVA
3: 100 kWh/kvarh/kVA
4: 1000 kWh/kvarh/kVA
5: 10000 kWh/kvarh/kVA
1 OUT 2 impulse duration:
1: 100 ms
2: 200 ms
3: 300 ms
4: 400 ms
5: 500 ms
6: 600 ms
7: 700 ms
8: 800 ms
9: 900 ms
High-order Low-order
word n° word n°
00
/
/
/
/
CRC 16
05 49F5
