CAUTION:
Be careful not to pinch your fin-
gers or thumbs between the battery and the base
plate when attaching the battery.
CAUTION:
When removing the battery, press
the lock button while holding the handle firmly.
Before removing the battery, set the waist belt to
the lowest position.
1
► 1. Handle 2. Lock button
2. Adjust the position of the waist belt. Pull up the
height adjustment lever, then adjust the position of the
waist belt by sliding the base plate, and then return the
lever.
► 1. Height adjustment lever 2. Base plate 3. Waist
belt
CAUTION:
When adjusting the position of the
waist belt, be sure to lay down the unit so that the
battery faces downward as shown in the figure.
NOTICE:
tighten the nut of the height adjustment lever.
When tightening the nut, do not tighten it excessively.
Otherwise, the height adjustment lever will not move.
2
► 1. Nut
NOTE: If it is difficult to slide the base plate, lift up
the stand slightly so that the stand does not touch the
ground, and then slide the base plate.
3.
hook and loop fastener as shown in the figure.
► 1. Adapter pocket
NOTE: The adapter pocket can be attached on either
left or right side of the waist belt.
1 2 3
4.
width adjustment belt.
► 1. Width adjustment belt
9 ENGLISH
If the height adjustment lever is loose,
1
Attach the adapter pocket to the waist belt with the
1
Adjust the width of the shoulder harness using the
1
