5. Function
The heavy duty flameproof control stations XADW series, made in aluminum, are mainly dedicated to
control.
Provided with push buttons, pilot lights, switches, potentiometers or ammeters are delivered with nickel-
platted cable entries (specific entries or painting upon on request).
They are available with standard functions such as push buttons Start/Stop or customized to meet specific
needs.
6. Technical data
The flameproof control stations XADW series described in this manual are certified II 2 GD and can operate
into the classified zones 1 and 2 for gases or 21 and 22 for dusts.
6.1. Caractéristiques
Certificat Europe (ATEX)
Standards accordance
Ex-codes
Temperature range
IP degree
Material
Cable entry
Mechanical endurance
6.2. Electrical apparatus that can be used
Product code
XADW12...
XADW13...
XADW22...
XAD019A12-08 – 01/12/2016
INERIS 03ATEX0145
EN / IEC 60079-0
EN / IEC 60079-1
EN / IEC 60079-31
Ex d IIB T6 Gb
ou
Ex d IIB T6 Gb T°Câble 75°C (Tamb. +60°C)
ou
Ex tb IIIC IP65-66 T85°C Db
Ambiante : -20°C ... +60°C
Stockage : -50°C ... +70°C
IP 65-66 according to IEC 60529
Aluminum
1 or 2 entries M20 ou ¾ '' NPT according to the series
Actuator : 5 million operation
Contact block : 1 million operation
Pilot lights
Contact
blocks
500 V
500 V
U max
10 A
I max
10 W
W max
500 V
500 V
U max
10 A
I max
10 W
W max
500 V
500 V
U max
10 A
I max
10 W
W max
Operating instructions
Flameproof control station - XADW series
Switches
Measuring
device
230 V
500 V
18 A
10 A
230 V
500 V
18 A
10 A
230 V
500 V
32 A
10 A
Terminals
Potentiometers
10 Ω... 100 KΩ
500 V
10 Ω... 100 KΩ
65 A
10 Ω... 100 KΩ
32 W
10 Ω... 100 KΩ
500 V
10 Ω... 100 KΩ
65 A
10 Ω... 100 KΩ
32 W
10 Ω... 100 KΩ
500 V
10 Ω... 100 KΩ
65 A
10 Ω... 100 KΩ
32 W
ENG
8/12
