Assembly & disassembly of side brush :
1. Release the screw in the main shaft of the
side brush before changing the side brush.
2. Press the side brush against the main shaft
and then fasten the screw.
Cleaning of main brush and floor brush :
1. Clear the hair or big dust particles on the brush
and floor brush regulary to improve the
cleaning performance. Clean the dust at the air
intake. Clean the wastepaper or small particles
by dust brush direcltly. Rotate the brush
carefully and cut by scissors or pull by hand the
hair, yarn and other twisted objects.
2. The cleaning of the main brush and floor brush can be done by reference to the assembly & disassembly.
Assembly & disassembly and cleaning of Left/Right wheel and front wheel :
Assembly & disassembly and cleaning of Left/Right wheel :
1. Release the screw of the left/right wheel by the screwdriver.
2. Take out the left/right wheel and clean them with the brush.
Don't wash them in water !
3. Place the left/right wheel in the original position, and tighten
the screw while assembling.
Assembly & disassembly and cleaning of front wheel :
1. Pull out the front wheel with your finger and tools and then clean it.
2. Insert and press the front wheel into the right position while assembling.
