Accessoires - Buchi Interface I-300 Pro Manuel D'utilisation

11 | Accessoires

11
122/126
Accessoires
BUCHI Bluetooth® Dongle, connects instrument
to smartphone via Bluetooth®
Needed for firmware updates and eSupport.
StatusLight cpl., incl. communication cable
Indicates the status of the instrument (instrument is ready
to use, has an error or is in operation).
AutoDest sensor. Incl. cap nut, seal GL14
For automatic distillation. Measures temperature of cooling
media and the vapor temperature. Vacuum is adjusted ac-
cording to cooling capacity of condenser. Meant to be used
with the Interface I-300 / I-300 Pro and glass assembly V, HP
or S.
Communication cable. BUCHI COM, 0.3 m, 6p
Enables connection between Rotavapor® R-300 / R-220 Pro,
Interface I-300 / I-300 Pro, Vacuum Pump V-300 / V-600,
Recirculating Chiller F-3xx, VacuBox and LegacyBox.
Communication cable. BUCHI COM, 1.8 m, 6p
Enables connection between Rotavapor® R-300 / R-220 Pro,
Interface I-300 / I-300 Pro, Vacuum Pump V-300 / V-600,
Recirculating Chiller F-3xx, VacuBox and LegacyBox.
Communication cable. BUCHI COM, 5.0 m, 6p
Enables connection between Rotavapor® R-300 / R-220 Pro,
Interface I-300 / I-300 Pro, Vacuum Pump V-300 / V-600,
Recirculating Chiller F-3xx, VacuBox and LegacyBox.
Communication cable. BUCHI COM, 15 m, 6p
Enables connection between Rotavapor® R-300 / R-220 Pro,
Interface I-300 / I-300 Pro, Vacuum Pump V-300 / V-600,
Recirculating Chiller F-3xx, VacuBox and LegacyBox.
Mini-DIN to DC-Jack, 300 mm
Meant to be used with 1 Vacuum Pump V-300 and 2 evapo-
rator systems with Interface I-300/I-300 Pro and Rotavapor®
of older generations. Connection between VacuBox and po-
wer adapter of the Interface I-300/I-300 Pro.
Communication cable. Mini-DIN, Y-piece, 2.0 m
Meant to be used with 1 Vacuum Pump V-300 and 2 Rota-
vapor® systems with the Interface I-300/I-300 Pro. Connec-
tion between VacuBox and Vacuum Pump V-300.
Communication cable. RJ45, 2 m
Connection between vacuum controller/interface and recir-
culating chiller or vacuum controller/interface and vacuum
pump.
Büchi Labortechnik AG
Réf. article
11067770
11068959
11059225
11058705
11058707
11058708
11064090
11062266
11062255
044989
Manuel d'utilisation Interface I-300 Pro
Schéma
