INSTRUCTIONS FOR USE

WIRING DIAGRAMS

(See Fig. K)
BAT Battery 24V
C1 Battery connector
C2 Battery charger signal connector
CH Battery charger 24V 25A
EB1 Function electronic board
EB2 Drive electronic board
EB3 Electronic board LED
EV1 Water solenoid valve
EV2 Recirculation solenoid valve (optional)
F1 Function electronic board fuse
F2 Drive electronic board fuse
HM Hour counter
K1 Key switch
LD1 Brush switch warning light
LD2 Extra pressure warning light
M1 Left brush motor
M2 Right brush motor
M3 Vacuum motor
M4 Brush-holder deck actuator
M5 Machine drive motor
M6 Water recirculation pump (optional)
R1 Machine drive speed potentiometer
R2 Machine drive maximum speed potentiometer
SW1 Brush switch
SW2 Extra pressure switch
SW3 Vacuum micro-switch
SW4 Brush release switch
SW5 Brush enabling micro-switch
SW6 Actuator position 0 micro-switch
SW7 Actuator position 1 micro-switch
SW8 Actuator position 2 micro-switch
SW9 Drive enabling micro-switch
SW10 Drive motor release switch
SW11 Water recirculation control switch (optional)
SW12 Water recirculation float switch (optional)
Color code
BK Black
BU Blue
BN Brown
GN Green
GY Grey
OG Orange
PK Pink
RD Red
VT Violet
WH White
YE Yellow

ELECTRICAL FUSES

Fuses
– Function electronic board fuse (100A) (7, Fig. E)
– Drive electronic board fuse (30A) (8, Fig. E)
6 Razor™ Plus 24D-26D-28D / Razor™ Plus 24C-28C — 909 5428 000(2)2005-01

ACCESSORIES/OPTIONS

In addition to the standard components, the machine can be
equipped with the following accessories/options, according
the machine specific use:
1. Gel batteries
2. Brushes of materials different from the standard ones
3. Pads of different materials
4. Squeegee oil-proof blades
5. Recovery water recirculation system
6. Service and parking brake
7. Front wheels and rear wheel of different materials
8. Shockproof rollers, oversize
For further information concerning the optional accessories,
contact an authorized Retailer.

USE

WARNING!
On some points of the machine there are some
adhesive plates indicating:
- DANGER
- WARNING
- CAUTION
- NOTE
While reading this manual, the Operator must pay particular
attention to these symbols.
Do not cover these plates for any reason and immediately
replace them if they are damaged.
BATTERY CHECK/SETTING ON A NEW
MACHINE
WARNING!
The electric components of this machine can
be seriously damaged if batteries are either
installed or connected improperly. The
batteries must be installed by qualified
personnel only. Set the function electronic
board and the battery charger according to the
type of batteries used (lead or gel batteries.
Check the batteries for damage before
installation.
Disconnect the battery connector and the
battery charger plug.
Handle the batteries with great care.
Install the battery terminal protection caps
supplied with the machine.
The machine can be equipped with:
– two 12V batteries
– four 6V batteries
– one 24V battery
connected according to the diagram shown in Fig. J (6).
