Recovery water tank emptying
1. Stop the machine by releasing the paddle (4, Fig. C).
2. Lift the brushes/pad-holder by means of the switch (2,
Fig. B).
3. Lift the squeegee by means of the lever (25, Fig. C).
4. Bring the machine to the appointed disposal area.
5. Empty the recovery tank by means of the hose (26, Fig.
C). After working, rinse the tank with clean water.
Solution tank emptying
6. Carry out steps 1 to 4.
7. Empty the solution tank by means of the hose (27, Fig.
C). After working, rinse the tank with clean water.
Cylindrical brush debris container emptying (only
for cylindrical brush-holder deck)
8. Stop the machine by releasing the paddle (4, Fig. C).
9. Lower the cylindrical brush-holder deck and remove the
debris container (26, Fig. J) by pulling it on one side by
means of the handle (27).
10. Empty and wash the debris container (26), and then
install it by engaging it on the retainers.

AFTER USING THE MACHINE

After working, before leaving the machine:
1. Remove the brushes/pad-holders according to the
following procedure:
– Brush/pad-holder: lift the deck and wait for the
warning light on the switch (2, Fig. B) to turn off; then
press the switch (6, Fig. B) until the
brushes/pad-holder is disengaged.
– Cylindrical brushes: lift the deck and wait for the
warning light on the switch (2, Fig. B) to turn off; then
turn the ignition key (10, Fig. B) to "0" to turn off the
machine.
Unscrew the handwheels (25, Fig. J) and remove the
lids (24).
Remove the cylindrical brushes (23).
Reinstall the lids (24, Fig. J) and screw the
handwheels (25).
2. Empty the tanks (5 and 6, Fig. J) and the debris
container (26, Fig. J) as shown in the previous
paragraph.
3. Perform the daily maintenance operations (see the
Maintenance chapter).
4. Store the machine in a clean and dry place, with the
brushes/pad-holders and the squeegee lifted or
removed.
Razor™ Plus 24D-26D-28D / Razor™ Plus 24C-28C — 909 5428 000(2)2005-01
INSTRUCTIONS FOR USE

PUSHING/TOWING THE MACHINE

When it is not possible to use the machine drive, to push/tow
the machine easily it is necessary to activate the drive cut-off
switch (36, Fig. C).
When the pushing/towing is over, reset the drive by means of
the switch (36, Fig. C).

MACHINE LONG INACTIVITY

If you foresee that the machine will not be used for more than
30 days, proceed as follows:
1. Perform the operations described in the paragraph After
Using The Machine.
2. Disconnect the battery red connector (30, Fig. C).

FIRST PERIOD OF USE

After the first period of use (first 8 hours) it is necessary to
carry out the following operations:
– Check the fixing and connecting parts for proper
tightening;
– Check the visible parts for integrity and leakage.

MAINTENANCE

The lifespan of the machine and its maximum operating
safety are ensured by correct and regular maintenance.
The following chart provides the scheduled maintenance. The
intervals shown may vary according to particular working
conditions, which are to be defined by the person in charge of
the maintenance.
WARNING!
The operations must be carried out with the
machine off and the battery disconnected.
Moreover, read carefully the instructions in the
Safety chapter before performing any
maintenance operation.
All scheduled or extraordinary maintenance operations must
be performed by qualified personnel, or by an authorized
Service Center.
This manual contains the Scheduled Maintenance Table and
describes only the easiest and most common maintenance
procedures.
NOTE:
For other maintenance procedures contained
in the Scheduled Maintenance Table or for
extraordinary maintenance operations see the
specific Service manual that can be consulted
at any Service Center.
