START-UP
Follow carefully the following 3 steps to start up the device:
•
Start-up of main unit
•
Start-up of radio sensors and search of sensors by the main unit
•
Setup of central unit
Since the device takes into account the altitude of the place of use,
it is advisable to carry out this setting at the place where the device is to
be used. Otherwise, the pressure measurement will not be accurate.
Before starting, inquire about the altitude and current pressure of
the locality where you are with the local weather forecast phone service,
port or airport.
STEP No. 1 – START-UP OF MAIN UNIT
Pull and remove the cover of the battery compartment located at the
back of the device.
Remove the insulating strip. The device uses 4 batteries AA.
Put the cover back in place and check that it is correctly fitted.
Your Easy Meteo can be installed in two ways : standing on its foot or
fixed on the wall.
Free standing :
Remove the cover fixed at the lower end of the tube at rear of device and
fit the foot to the device using the notch provided.
Wall fixing:
Fix the wall fixing support (black plastic part) onto the wall.
Whilst holding the device on each side with the index finger holding the
top of it. Slide the tube of the device from top to bottom into the wall
support using notches provided.
The wall fixing piece offers 7 different positions for directing the device.
If you wish to change the device's direction, gently release the device from
its wall fixing support, sliding upwards and perform the same handling
as described previously to put it back in the position of your choice.
Perform the above operations with caution avoiding
scratching the paint of the device's tube.
Never try changing the device's direction without first
releasing it from its support.
On power on, the main unit produces a long 'beep' with a bluish-lighted
line appearing simultaneously on the front panel. Then the LCD display
switches on and the following indications are displayed from top to
bottom:
• Date 31.01 or time 0.00 alternately
• The moon phase
• A weather pictogram
• Inside temperature and hygrometry
• Absolute pressure measured at the local altitude where the product is
used
The right-hand column of the graphic area is lit and will represent the first
pressure average over a 1/2 h.
