Contents
Chapter 1. Product Introduction
1.1
1.2
1.3
Chapter 2. Installation Guide
2.1
2.2
2.3
2.4
2.5
2.6
2.7
Chapter 3. Leads Installation Guide
3.1
3.2
3.3
Chapter 4. Other
4.1
1
Specification
02
02
03
05
06
08
10
Accessory
11
12
Figure
13
14-19
14-19
14-19
20
Micro Case
Case Type
239 x 280 x 456 mm
Dimension
(H*W*D)
(9.4 x 11 x 17.9 inch)
Net Weight
5.8 kg / 12.8 lb
Side Panel
No Window
Material
SECC & Aluminum
Front (intake) :
90 x 90 x 25 mm fan (1200rpm, 16dBA )
Rear (exhaust) :
Cooling System
60 x 60 x 25 mm fan x 2 (1500rpm,18dBA)
Drive Bays
-Accessible
2 x 5.25", 1 x 3.5"
-Hidden
2 x 3.5", 2 x 3.5"
Expansion Slots
4
9.6" x 9.6" (Micro ATX), Mini-ITX
Motherboards
I/O Ports
USB 3.0 x 2 , HD Audio x 1
PSU
Standard PS2 PSU
Top: 1 x 120mm or 1 x 140mm
Radiator Support
(Converted from Radiator Bracket)
Parts Name
Q'ty
6#32 screw
8
4
O5 screw
6#32 hexagon screw
28
M3 screw
10
Thumb screw
1
Space support
1
Buzzer
1
Movable tie
5
Strap tie
2
2.5" Tool-free clip
2
Radiator Bracket
1
Used for
3.5" HDD
Fan
HDD, Power, Motherboard,
PCI bracket
FDD, ODD
Backup
Motherboard
Motherboard
Arrange wire
Arrange wire
2.5" HDD
For 12 or 14 cm Radiator
2
