- Page 1 Foto Gong PIR Wired Type 33-410 Brugervejledning User guide Gebrauchsanweisung Notice d’utilisation Bruksanvisning...
-
Page 2: Mounting/Connection
User guide PIR Wired 33-410 Content 44-041 23-041 23-410 3 m. Mounting/Connection 10 cm. 2,5 m. 2,5 m. Approx. 1 m. max 6 m. Bottom view – inside Adjust PIR Wire connection On/Off Adjust sensitivity Adjust lens angles... -
Page 3: Adjustment
Foto Gong central Central 23-410 Inside view Connections 1 2 3 4 5 6 7 8 9 10 11 12 Adapter 23-041 44-041 Adjustment Sound settings Sound options Sound 1 Sound 2 (Factory Settings) Sound 3 Backdoor Frontdoor Ch. 2 Ch. -
Page 4: Options - Accessories
Options – accessories PIR – Front door Ch. 1 Foto Gong central Main room Back room PIR – Back door Ch. 2 Extra speaker Sound settings Sound options Sound 1 Sound 3 Sound 2 Sound 4 Power on Frontdoor Backdoor Example –... - Page 5 Options – accessories 44-041 PIR 44-041 PIR Counter 23-209 Front door Ch. 1 Back door Ch. 2 (optional) Extra speaker Max. 1 unit 44-072 IR 44-072 IR can be Front door Ch. 1 Back door Ch. 2 conected 23-410 23-041 Push button Push button Adapter...
- Page 6 Teknisk data (Foto Gong – PIR trådet) Central 23-410: Tilslutningsspænding 12 V DC Tællerudgang NPN open collector Ic < 50 mA Vceo < 50 V DC Impulstid 160 ms Ch 1 max. 4 stk. Sensor PIR 44-041 eller 2 stk. Sensor IR 44-072 Ch 2 max.
- Page 7 Technical data – (Foto Gong - PIR wired) Central unit 23-410: Connection voltage 12 V DC Counter output NPN open collector IC < 50 mA, VCEO < 50 V DC Pulse time 160 ms Ch 1 max. 4 pcs. Sensor PIR 44-041 or 2 pcs.
- Page 8 Technische Daten – (Foto Gong - PIR) Zentrale 23-410: Anschlußspannung 12 V DC Zählerausgang NPN open collector IC < 50 mA, VCBO < 50 V DC Impulsdauer 160 ms Ch 1 max. 4 stück Sensor PIR 44-041 oder 2 stück Sensor IR 44-072 Ch 2 max.
-
Page 9: Caractéristiques Techniques (Foto Gong - Pir)
Caractéristiques techniques (Foto Gong - PIR) Central 23-410: Tension de connexion 12 V DC Sortie compteur NPN collecteur ouvert IC < 50 mA, VCEO < 50 V DC Temps impulsion 160 ms Ch 1 max. 4 pièces Sensor PIR 44-041 ou 2 pièces Sensor IR 44-072 Ch 2 max. - Page 10 Tekniska data (Foto Gong - PIR) Central 23-410: Anslutningsspänning 12 V DC Räknarutgång NPN open collector, IC < 50 mA, VCEO < 50 V DC Impulstid 160 ms Ch 1 max. 4 stk. Sensor PIR 44-041 eller 2 stk. Sensor IR 44-072 Ch 2 max.
- Page 11 Technische gegevens (Foto Gong - PIR) Centrale 23-410: Aansluitspanning 12 V DC Telleruitgang NPN open collector IC < 50 mA, VCBO< 50 V DC Inpulsduur 160 ms Ch 1 max. 4 stk. Sensor PIR 44-041 of 2 stk. Sensor IR 44-072 Ch 2 max.
- Page 12 Servodan A/S Stenager 5 DK-6400 Sønderborg Denmark info@servodan.dk tel. +45 7442 4726 fax +45 7442 4035 www.servodan.dk...
