ENGLISH
IMPORTANT: The instruction manual you are holding includes essential information on the safety measures to be
implemented for installation and start-up. Therefore, the installer as well as the user must read the instructions
before beginning installation and start-up.
Keep this manual for future reference.
To achieve optimum performance of the LumiPlus Flexi, follow the instructions provided below:
1. VERIFY THE CONTENTS OF THE PACKING:
- LumiPlus Flexi.
- Power supply 100-240V AC - 24V DC.
- Bag of accessories: FlexiNiche cable gland, FlexiRapid cable gland, 1 seal, 1 O-ring seal, gasket, cable and mounting
screws (1 for screwing the spotlight to the faceplate + 3 for screwing the cable gland).
- Warranty booklet.
- Instruction manual.
The LumiPlus Flexi 71201, 71201WW, 71202 and 71202WW do not need any control as they only emit monocolor
light.

2. GENERAL CHARACTERISTICS:

LumiPlus Flexi has been designed to be used fully submerged in water. It is a Class III electric apparatus with very low
safety voltage (24VDC). LumiPlus Flexi is class 116, in accordance with standard EN 50065.
LumiPlus Flexi complies with IPX8 - 2 m.
LumiPlus Flexi complies with international safety standards for lights, especially the EN 60598-2-18 standard: LIGHTS
PART 2: SPECIFIC REQUIREMENTS SECTION 18 LIGHTS FOR SWIMMING POOLS AND SIMILAR APPLICATIONS.
The manufacturer is not responsible in any circumstances for assembly, installation or start-up of any electric compo-
nents which have been inserted or handled at locations other than its own premises.
3. INSTALLATION:
• To correctly light a swimming pool we recommend you:
Install a LumiPlus Flexi V1 for every 20 m² of water surface.
Install a LumiPlus Flexi V2 for every 25 m² of water surface.
Note: Strongly recommended for pools in light colors. In pools with a dark or stainless steel finish, it is recommended
to use more spotlights per m².
• It is the responsibility of the fitter to ensure that the area around the connectors is completely watertight.
• The junction boxes should be placed at least 2 m from the edge of the pool or water facility.
• The power supply that feeds the LumiPlus Flexi should be installed at a distance of 3.5 m from the edge of pool or
water facility.
• Cable ducts laid less than 3.5 m away from the edge of the pool must not be made of metal.
• The smallest cable cross-section that fits the LumiPlus Flexi is a 2 x 1 mm² H07RN-F.
• The largest cable cross-section that fits the LumiPlus Flexi is a 2 x 2,5 mm² H07RN-F.
• Should the current H07RN-F cable have a cross-section of 2 x 4 mm² or 2 x 6 mm², an underwater splice should
be made. To ensure that the LumiPlus Flexi projector works properly, we recommend using AstralPool's underwater
connection kit (code 32803).
UNDER NO CIRCUMSTANCES SHOULD SCREWS OTHER THAN THOSE SUPPLIED BE USED FOR SCREWING THE
LUMIPLUS FLEXI CABLE GLAND AS THEY COULD PIECE IT AND RESULT IN WATER GETTING INTO IT.
MODELS AVAILABLE ACCORDING TO CHARACTERISTICS
LumiPlus DC V1
Monocolour
71201 71201WW
ATTENTION
LumiPlus DC V2
Monocolour
71202 71202WW
