Specifications; Keybord - Consort C732 Mode D'emploi

Ranges pH
mV
rH 2
µW
Conductivity
Resistivity
Salinity
°C
Resolution 0.01 pH, 1 mV, 0.001 µS/cm, 1 Ω.cm, 0.01 ppm, 0.1°C
Inputs
BNC input for a pH electrode
BNC input for a mV electrode
BNC input for a 2-pole conductivity cell
DIN-8 input for a 4-pole conductivity cell
BANANA input for a Pt1000 temperature probe
Temp. Comp.
automatic with Pt1000 or manual
Digital output programmable RS232, 150...4800 b/s, for bi-directio nal com-
munication with a computer or printer
Analogue output
0...2 V, ca 8 kΩ, programmable 8 bit D/A
Display
8+4 digit/character, 13 mm LED display
Keys 8 tactile membrane keys
Ambient temp.
4...40°C
Rel. Humidity
0...90 % (non-condensing!)
Power supply
210-250 V~ (* 105-125 V~), 50/60 Hz, max. 4 VA
Cabinet rugged ABS/metal cabinet
Dimensions
300 x 180 x 120 mm
Weight
2.4 kg
MODE = Selects all modes or escapes from error traps, calibration proce-
dures, etc..by returning to the original mode.
CAL
= Starts or proceeds a calibration or a function.
Ù/Ú = Button for entering a value or for selecting a function.
SET = Installs the meter according your application.
HOLD
= Holds display when measuring.
RES
= Changes resolution/units of the display.
PRINT = Displayed value is printed through the RS232 output.
ON/OFF
= Switches the instrument on or off.
C732 C732
0...14 pH
±2000 mV
0...42 rH 2
0...400000 µW
0...20/200/2000 mS/cm (cc = 0.1/1/10)
0...2/20/200 MΩ.cm (cc = 0.1/1/10)
0...10 %
0...100°C

Specifications

Specifications
Keyboard Keyboard
6 6 / 43 / 43
