7
Align front cover and trim bars, then install with
supplied M5x20mm screws (4pcs, 4mm hex drive).
Recommended configuration for specific vehicles
Table 1: Recommended vehicle settings
Vehicle
2015+ F-150 51" (max)
2018+
51" (max)
Silverado/Sierra
2007+ Wrangler 40" (min)
2018+ RAM 51" (max)
Front cover
Trim bars
Width Inner Foot
yes
yes
no
yes
Outer Foot Outer Foot
(front) (rear)
yes yes
yes yes
yes yes
yes no
https://manual-hub.com/
Amp Tray Notes
yes
yes
Remove inner
no foot and install in
outer location
yes
