Quick Reference Guide: Maintaining Your Suction Power
Thank you for purchasing an Infinity vacuum. To ensure your vacuum never loses suction, you must perform the following
regular maintenance tasks. Refer to your Owner's Manual for step by step instructions.
Note: This maintenance schedule is based upon normal household use. If you vacuum more frequently, or pick up large
quantities of fine materials such as carpet cleaning powder, flour, drywall dust or other fine materials, you will need to
perform more frequent maintenance to maintain the original suction power.
WARNING: To avoid the risk of electrical shock, never operate the vacuum with a wet cyclonic chamber, wet pre-
motor filters, or a wet True HEPA filter. Let the pre-motor filters, dust cup, debris screen and cyclonic chamber air
dry for 24 hours after cleaning.
1. Bottom Emptying the Dust Cup:
Empty the dust cup after each use and each time it reaches
the "MAX" fill line. (Fig. 1, Fig. 2)
Press
Fig. 1
2. Cleaning the Upper Cyclonic Chamber:
Empty, rinse and air dry the cyclonic chamber completely
(found on top of your dust cup). This will need to be done
approximately every 3 months under normal household use,
but always prior to the dust in the cyclonic chamber reaching
the "MAX" fill line. If you can't see the dirt level, clean every 3
months. Let air dry completely with the bottom door open
before re-installing into the vacuum. (Fig. 3, Fig. 4, Fig. 5,
Fig. 6, Fig. 7)
Fig. 3
Fig. 6
3. Cleaning the Debris Screen:
Clean the dust cup debris screen if any residual dirt
remains on the screen after emptying the dust cup.
(Fig. 8, Fig. 9, Fig. 10)
Hold
From the
bottom
Fig. 8
Fig. 9
Printed in China
Fig. 2
Fig. 5
Fig. 4
Fig. 7
Hold &
Twist
Debris
Screen
Fig. 10
COPYRIGHT© EURO-PRO OPERATING LLC 2006
4. Cleaning the Pre-Motor Filters:
Rinse, squeeze and air dry the pre-motor filters completely
every 3 to 5 months, depending on use. You can continue
vacuuming using the extra set of pre-motor filters included
while you wait for the original pre-motor filters to dry.
(Fig. 11, Fig. 12, Fig. 13)
Foam Filter
Felt Filter
Note:
To maintain suction power, clean the pre-motor filters
every 3 to 5 months. The filter indicator light will flash only as a
reminder after the vacuum has experienced a decrease in
suction power. If the light is flashing, you can restore suction
power by following the cleaning instructions above.
5. Cleaning the Post Motor Lifetime Washable True
HEPA Filter:
Tap clean, rinse and air dry the HEPA filter for 24 hours at
least every 3 years. (Fig. 14, Fig. 15, Fig. 16)
Fig. 14
EURO-PRO Operating LLC
Tel.: 1 (888) 866-9600
www.infinityvac.com
Fig. 11
Fig. 13
Fig. 12
Fig. 16
Filter
Housing Base
Felt Filter
Foam Filter
Filter Housing
Fig. 15
Rev. 06/06A
