Light Commercial Wall Exhaust Fans
CANARM Ltd. warrants every new fan to be free of defects in material and workmanship, to the extent that, within a period of one
year from the date of purchase CANARM Ltd. shall either repair or replace at CANARM's option, any unit or part thereof, returned
freight prepaid, and found to be defective. This warranty does not include any labour or transportation costs incidental to the
removal and reinstallation of the unit at the user's premises.
Components repaired or replaced are warranted through the remainder of the original warranty period only. This warranty applies
to the original purchaser-user only; it is null and void in case of alteration, accident, abuse, neglect, and operation not in
accordance with instructions.
NOTICE: No warranty claims will be honored by CANARM Ltd. unless prior authorization is obtained.
Read Instructions Completely Before Installation & Save For Reference
Congratulations on the purchase of your quality built direct drive, wall exhaust ventilation fan. Used for general exhaust ventilation, these
fans come fully assembled and all fans are tested for proper operation before shipping.
INSTALLATION
Installation is fast and simple. A sturdy framed wall opening should be prepared in advance to the size indicated for your fan in the
charts. With lag bolts for wooden frames or nut, bolt and lock washers for steel frames, secure the fan using the four mounting holes
provided, one in each corner of the fan. (SD/P Series only).
SD Exhaust Fans:
These models have a rugged, welded steel box housing with a powder coated finish and aluminum exhaust louvers. The louvers open
automatically when the fan starts up and close when the fan stops.
Installation or Product problems? Do not return to store of purchase.
Contact Canarm Service at 1-800-265-1833 (CANADA) 1-800-267-4427 (U.S.A.)
1-800-567-2513 (EN FRANCAIS) Monday to Friday 8:00 - 5:00pm e.s.t.
SD08/10_AX08/10_P08/10-M 09/26/22
SD08/SD10/AX08/AX10/P08/P10
Instruction Manual
WARRANTY
A X A
MODEL
B
SQUARE
SD08
13 1/4"
7 1/2"
SD10
15 1/4"
7 1/2"
N (# OF
C
D (c/c)
E SQR
LOUVRES)
4"
12"
10 3/4"
4"
14"
12 3/4"
FRAMING
2
11" x 11"
3
13" x 13"
Page 1 of 2
