BMB MEDICAL I-MOVE EZ-GO Manuel D'utilisation page 42

1.1.1 I-MOVE TRANSFER CHAIR
REFERENCE
DESCRIPTION
SAFE WORKING LOAD
WEIGHT
OVERALL DIMENSION
CUSHION AND BACK SIZE
BACK HEIGHT
EQUIPMENT
OPTIONS
BMB MEDICAL – I-MOVE – 2VTRS042022
TECHNICAL CHARACTERISTICS
I-MOVE
PATIENT TRANSFER CHAIR
200 kg (maximum acceptable weight comprising the weight of the
patient, the mattress and the accessories)
35 kg
105 x 75 x 100 cm
46 x 46 cm
55 cm
* Overall dimensions : 105 (length) x 75 (width) x 100 (height) cm
* Dimensions seat and back: 46 x 46 cm
* Seat height : 55 cm
* Steel frame epoxy coated, white RAL 9003
* Patient file holder
* Back wheels Ø 300 mm with central braking system, can be
operated in stand position by the accompanying person
* Front swivel wheels Ø 125 mm
* Sliding and self-blocking foot rest
* Polyurethan armrests, can be folded up
* Anti-shock protection
* Cushion in foam - Thickness 5 cm
* Seamless finish, vinyl coating
* Colour range : fuchsia, green, blue
Removable IV pole, 2-stage, 2 hooks.
Fixed IV pole, 2-stage, 2 hooks.
Removable IV pole, 2-stage, 4 hooks.
Anti-static system.
U-shape anti-theft, fitted with 2 hooks infusion holder.
Accessory basket.
Holder for oxygen cylinder.
Equipment for leg rest (pair).
Adjustable leg rest (1 piece).
Coin acceptor for 1€ coin or equivalent.
Coin acceptor for specific token.
Additional specific token.
Wall fixation.
Hooks to hold bags.
42
