Characteristics
• Low-noise diaphragm pump
• Integrated check valve
• Compact design
• Easy installation
• Potential-free alarm contact (NC)
Application
(grau)
The Eckerle condensate pump E200 is intended for pumping
(schwarz)
condensate and for installation below the air conditioning unit.
(weiß)
(lila)
Technical Data
Electrical data
Power consumption
operation
Alarm contact
(potential-free)
Max. delivery rate
Max. delivery height
Dimensions (L x W x H)
Pressure hose Ø
Protection class
Weight
Performance
(schwarz)
(weiß)
(lila)
(grau)
Electrical connections
Turn off the power at the fuse box before doing any work on the
electrical connections. All electrical connections must comply
with local and/or national regulations or standards.
1. The pump is equipped with a 1.5m power cord.
2. The EE200 pump is also equipped with an overflow alarm
contact (NC), which must be connected! The alarm cont-
act switches with a delay of approx. 5 seconds (see alarm
connection).
Test run
Function test Connect the power cable of the pump. Manually
fill the tank with water until the pump turns on.
Maintenance
Preventative Maintenance: Annually before the start of the sea-
son.
Troubleshooting
If problems occur with the pump, please note the following in-
formation:
1. Pump is not running
A. Check the power supply to the pump
100 - 240V 50/60Hz
B. Check whether condensate is being pumped out or is
present in the tank.
4W, Standby 1,5W
C. Check whether the float can move freely, as well as the
clean condition of surfaces in contact with the medium
and/or moving components.
Max. 240V, 5A ohmic load,
D. Check whether the pump's drain or inflow line is clog-
normally closed (NC), cable
ged. Attention: If these lines are blocked, the pump can
colors red, white
be damaged!
20 l/h
2. The pump makes a lot of noise
10 m
A. Check the tank for dirt residue and remove it if present.
Please note the maintenance and cleaning instruc-
315 x 54 x43 mm
tions.
6 x 1,5 mm
3. The pump runs, but does not deliver
IP20
A. Test whether the float may be stuck in the upper po-
sition
500g
B. Check the height of the drain line with the max. permis-
sible values (see technical data)
C. Check whether the drain line is blocked and clean it if
necessary.
Warranty
1 year. This warranty applies to parts that are defective in ma-
terials or workmanship and is limited to the replacement or re-
pair of the defective parts. Labor costs and possible secondary
damages cannot under any circumstances serve as a basis for
a complaint. The returned devices must be complete and must
contain a written list of the specified defects. We decline all
liability in the event of non-conforming installation or non-com-
delivery height (m)
pliance with specifications or maintenance.
Conformity
All data provided serves solely to describe the product and are
not to be understood as guaranteed properties in the legal sen-
se.
Technical changes reserved.
