RDC380 REMOTE CONTROL
Fig.3 (display)
BT connection
Slope X-axis
Slope Y-axis
Manual mode
Hor./Vert. line
Fig.4 (keyboard)
On/Off
Bluetooth
Detector mode
Power+ mode
Flash mode
Digital slope
on/off
Tilt mode on/off
Tilt mode on/off
1
2
3
On/Off /Warning
Levelling
Slope mode
1.
2.
Detector mode
3.
HighPower mode
4.
Flash mode
5.
6.
7.
8.
The laser is equipped with a 1/4" connection. To
mount the laser on a tripod with 5/8" connection, the
laser should be placed on the tripod complete with
mounting foot.
X/Y axis selection
Slope up
Slope down
MOUNTING BASE/CLAMP
4
Fig.5
Adjustable clamp
Clamp positions
Clamping lever (press the lever to slide it into the desired
position)
Slide for rotating the foot
Rotating foot
1/4" instrument connection
Knob for adjusting the position of the foot
Hanging eye
EN
8
7
6
5
19
