Page 1
LEVELFIX MCL380 GEBRUIKSAANWIJZING USER MANUAL MANUEL D’UTILISATION...
Page 3
MOGELIJKE FOUTEN --------------------------------------------------------------------------------------------------------------12 GARANTIE EN AANSPRAKELIJKHEID ---------------------------------------------------------------------------------------- 12 LADEN VAN DE BATTERIJ ------------------------------------------------------------------------------------------------------- 12 MILIEUZORG ------------------------------------------------------------------------------------------------------------------------ 13 Wij danken u voor de aankoop van een LEVELFIX product. Lees aandachtig deze gebruiksaanwijzing, zodat u de laser op de best mogelijke manier kunt gebruiken.
Page 4
PICTOGRAMMEN Al onze apparaten worden in de fabriek gecon- troleerd en zijn perfect afgesteld. Het toestel kan echter door schokken worden ontregeld of zijn ALGEMENE WAARSCHUWING nauwkeurigheid verliezen. Controleer zelf regelmatig de nauwkeurigheid van het toestel, in het bijzonder bij aanvang van LEES DE HANDLEIDING grote meetwerkzaamheden.
Page 5
Heeft u de afstandsbediening even niet bij de hand? De laser is ook te bedienen met uw smartphone via de gratis LEVELFIX Connect app. De multifunctionele wandhouder kan met magneet, schroeven of nagels worden vastgezet, zodat de laser in alle mogelijke situaties kan worden opgesteld.
Page 6
FUNCTIES EN TECHNISCHE GEGEVENS IDENTIFICATIE De MCL380G is dankzij de unieke combinatie van techniek- en en eigenschappen een veelzijdige laser. Geschikt voor werkzaamheden zowel binnen als buiten, op korte of lange afstand. OPNAME Laser 1/4” Multifunctionele houder 1/4” en 5/8” ZELFNIVELLERING Zelfnivelleringsbereik +/- 4°...
Page 7
RCD380 AFSTANDSBEDIENING MONTAGEVOET/-KLEM Afb.3 (display) BT verbinding Aan/Uit/Waarschuwing Nivelleren Afschot X-as Afb.5 Afschot modus Verstelbare klem Afschot Y-as Klem posities Ontvanger modus Klemhendel (druk de hendel in om deze in de gewenste Manuele modus positie te schuiven) HighPower modus Schuif voor het draaien van de voet Hor./Vert.
Page 8
Tilt functie GEBRUIK VAN HET INSTRUMENT Auto/Manuele modus Druk eenmaal op de aan/uit toets om de laser in te schakelen. Houd de aan/uit toets 3 seconden De Tilt-functie houdt in de gaten dat het ingestelde ingedrukt om de manuele modus in niveau niet gaat afwijken.
Page 9
Afschot functie manueel Afschot richting Druk eenmaal op de aan/uit toets om de laser in te schakelen. Houd de aan/uit toets 3 seconden ingedrukt om de manuele modus in te schakelen. Druk eenmaal op de afschot toets om het gewenste afschot op de X-as in te stellen. Druk op de pijlknop omhoog om het per- centage te verhogen.
Page 10
CONTROLEREN VAN DE CONTROLEREN VAN DE HORIZONTALE VERTICALE LIJNEN UITLIJNING Afb.6 Afb.7 We bevelen aan om regelmatig de horizontale uitlijning Om de loodlijn van het instrument te controleren, van de laser te controleren. Volg daarvoor de volgende volgt de u volgende stappen: stappen: •...
Page 11
CONTROLEREN VAN DE TOEPASSINGEN 90° HOEKEN Afb.8 • Plaats het instrument op 5 m van twee muren met een hoek • Zet de laser aan door twee keer op de AAN/UIT- knop te drukken. Teken punt A af op de vloer. •...
Page 12
ONDERHOUD GARANTIE EN AANSPRAKELIJKHEID • Behandel meetinstrumenten met zorg. De garantieperiode bedraagt 4 jaar. De garantie geldt niet voor storingen of defecten die te wijten zijn aan: • Reinig het toest el na elk gebruik met een zacht doekje. • Bevochtig indien nodig het doekje met water.
Page 13
MILIEUZORG CE VERKLARING Het symbool met de doorgestreepte afvalbak Wij verklaren dat de laser voldoet aan de eisen van Richtlijn op wielen betekent dat, bij afdanking, 2004/108 / CE. het product in de Europese Unie gescheiden moet worden ingezameld voor recycling. Dit geldt zowel voor het product zelf als voor alle met dit symbool gekenmerkte toebehoren.
Page 15
CONTENTS SYMBOLS ---------------------------------------------------------------------------------------------------------------------------- 16 GENERAL SAFETY INSTRUCTIONS ------------------------------------------------------------------------------------------ 16 LASER SAFETY INSTRUCTIONS------------------------------------------------------------------------------------------------ 16 INSTRUCTIONS AND WARNINGS DISPLAYED ON THE DEVICE ---------------------------------------------------- 17 INTRODUCTION ------------------------------------------------------------------------------------------------------------------- 17 TECHNICAL FUNCTIONS AND DATA --------------------------------------------------------------------------------------- 18 IDENTIFICATION ------------------------------------------------------------------------------------------------------------------- 18 RCD380 REMOTE CONTROL --------------------------------------------------------------------------------------------------- 19 MOUNTING BASE/CLAMP ------------------------------------------------------------------------------------------------------ 19 USE OF THE INSTRUMENT ----------------------------------------------------------------------------------------------------- 20 CHECKING THE HORIZONTAL LINE ----------------------------------------------------------------------------------------- 22 CHECKING THE VERTICAL LINES -------------------------------------------------------------------------------------------- 22...
Page 16
The user must regularly check the precision of the machine, particularly before carrying out substantial work. READ THE MANUAL Levelfix company shall accept no responsibility for problems regarding the construction, installation, manufacture or assembly which may result from improper use of the device.
Page 17
Tilt function on or off . Don’t have the remote control at Technical information relating to lasers. hand? You can also operate the laser using your smart- phone via the free LEVELFIX Connect app. > Located the back of the device under the battery...
Page 18
TECHNICAL FUNCTIONS AND DATA IDENTIFICATION The MCL380G is a versatile laser thanks to its unique combina- tion of technologies and features. Suitable for both indoor and outdoor work, at short or long distances. THREAD Laser 1/4” Multifunctional mount 1/4” and 5/8” SELF-LEVELLING Self-levelling range +/- 4°...
Page 19
RDC380 REMOTE CONTROL MOUNTING BASE/CLAMP Fig.3 (display) BT connection On/Off /Warning Levelling Slope X-axis Fig.5 Slope mode Adjustable clamp Slope Y-axis Clamp positions Detector mode Clamping lever (press the lever to slide it into the desired Manual mode position) HighPower mode Slide for rotating the foot Hor./Vert.
Page 20
Tilt function USE OF THE INSTRUMENT Auto/Manual mode Press the on/off key once to switch on the laser. Press and hold the on/off key for 3 The Tilt function monitors that the set level will not seconds to switch on manual mode. deviate.
Page 21
Slope function manual Slope direction Press the on/off key once to switch on the laser. Press and hold the on/off key for 3 seconds to switch on manual mode. Press the slope key once to set the desired slope on the X axis. Press the up arrow button to increase the percentage.
Page 22
CHECKING THE HORIZONTAL LINE CHECKING THE VERTICAL LINES Fig.6 Fig.7 We recommend regularly checking the horizontal To check the plumb of the instrument follow these alignment of the laser. To do so, follow the following steps: steps: • Choose a doorway with a clearance of approx. 2 •...
Page 23
APPLICATIONS CHECKING THE 90° ANGLES Fig.8 • Place the instrument 5 m from two walls at an angle • Turn the laser on by pressing the ON/OFF button twice. Mark off point A on the fl oor. • Mark off point B on the wall at a height of 1 m. and then point C at the same height on the other wall.
Page 24
This may cause the laser beam windows to fog up and the electronic connections to oxidise. Levelfix company shall accept no responsibility for problems regarding the construction, installation, manufacture or assembly which may result from a machine failure due to...
Page 25
ENVIRONMENT PROTECTION CE DECLARATION OF CONFORMITY The crossed-out wheeled bin means that We declare that the laser meets the requirements of Directive within the European Union the product 2004/108 / EC. must be taken for separate collection at the product end-of-life. This applies to your device but also to any accessories marked with this symbol.
Page 27
GARANTIE ET RESPONSABILITÉ ---------------------------------------------------------------------------------------------- 36 CHARGE DE LA BATTERIE ------------------------------------------------------------------------------------------------------- 36 PROTECTION DE L’ENVIRONNEMENT ------------------------------------------------------------------------------------- 37 Nous vous remercions de votre achat du laser automatique LEVELFIX afi n d’utiliser au mieux les possibilités de votre laser, lisez attentivement ce manuel d’utilisation.
Page 28
Tout utilisateur doit vérifier la précision de son instrument régulièrement et en tous cas avant LIRE LA NOTICE tous gros travaux. LEVELFIX n’accepte aucune responsabilité suite à des problèmes de construction, implan- tation, fabrication, montage qui pourraiten résulter d’un mauvais fonctionnement de l’appareil.
Page 29
à portée de main ? Vous pouvez également commander le laser à l’aide de votre smartphone via l’application gratuite LEVELFIX Connect. Le support mural multifonctionnel peut être fi xé à l’aide d’un aimant, de vis ou de clous, ce qui permet d’installer le laser dans toutes les situations possibles.
Page 30
FONCTIONS ET DONNÉES TECHNIQUES IDENTIFICATION le laser LEVELFIX est parfaitement polyvalent pour tous les travaux d’intérieur avec récepteur d’extrieur FILETAGE Laser 1/4” Support 1/4” et 5/8” MISE EN STATION AUTOMATIQUE Plage de calage automatique +/- 4° PRÉCISION Fig.1 ≤ 1.5mm / 10m...
Page 31
TÉLÉCOMMANDE RCD380 PIED DE MONTAGE / PINCE Fig.3 (affi chage) Connexion BT On/Off /Warning Mise à niveau Décalage de l’axe X Fig.5 Mode pente Pince réglable Décalage de l’axe Y Positions de la pince Mode récepteur Mode manuel Levier de serrage (appuie sur le levier pour le faire gliss- er dans la position désirée).
Page 32
Fonction Tilt UTILISATION DE L’INSTRUMENT Mode Auto/Manuel Press the on/off key once to switch on the laser. Press and hold the on/off key for 3 La fonction Tilt permet de contrôler que le niveau seconds to switch on manual mode. réglé...
Page 33
Manuel de la fonction de pente Direction de la pente Appuyez une fois sur la touche marche/arrêt pour allumer le laser. Appuyez sur la touche marche/arrêt pendant 3 secondes pour activer le mode manuel. Appuyez une fois sur la touche de pente pour défi nir la pente souhaitée sur l’axe X.
Page 34
CONTRÔLE DE LA LIGNE HORIZONTALE CONTRÔLE DES LIGNES VERTICALES Fig.6 Fig.7 Il est recommandé de vérifi er régulièrement le niveau Pour vérifi er l’aplomb de l’instrument, procédez de votre laser en suivant les étapes suivantes : comme suit : • Installer l’appareil entre deux murs, à...
Page 35
APPLICATION CONTRÔLE DES ANGLES À 90 ° Fig.8 • Placez l’instrument à 5 m de deux murs, de biais. • Allumez le laser en appuyant deux fois sur le bou- ton ON/OFF. Marquez le point A sur le sol. • Marquez le point B sur le mur à...
Page 36
Les fenêtres du faisceau laser risquent alors de RÉGULI ÈREMENT ET AVANT TOUS GROS TRAVAUX . s’embuer et les connexions électroniques de s’oxyder. LEVELFIX n’accepte acune responsabilité suite à des problémes de construction, implantation, fabrication, montage qui pourrait POSSIBILITÉS D’ERREURS résulter d’une défaillance de l’appareil due à...
Page 37
PROTECTION DE L’ENVIRONNEMENT DÉCLARATION DE CONFORMIT É CE Le symbole de la poubelle sur roues barrée Nous soussignés, déclarons que le laser d’une croix signifie que ce produit doit faire répond aux exigences de la directive 2004/108/CE. l’objet d’une collecte sélective en fin de vie au sein de l’Union européenne.
Page 38
FOR MORE INFORMATION: LEVELFIXINSTRUMENTS.COM VERSION 2025.02.24...
