Probasics K4 Deluxe Mode D'emploi page 10

INSTALLING/REMOVING THE FRONT RIGGINGS
B
NOTE:
The footplate will be on the inside of the wheelchair
when locked in place.
4. Repeat steps 1-3 for the opposite side of the wheelchair.
5. To release the front rigging, push the footrest release lever
inward, rotate footrest outward. To remove the front rigging,
lift and remove from hinge pins.
ANTI-TIPPER ADJUSTMENT
C
freely move the anti-tipper up and down to the desired height.
Once you find the correct height setting, release the red
buttons. Ensure that the anti-tipper is locked in place. You will
hear an audible click once it is locked into place.
ATTACHING 2" SEAT EXTENDER
1. Remove tube end caps and U-clips from either side of the
wheelchair seat rails.
2. Take the seat extender attachment with hook and loop side
up and align into corresponding seat rail tubes. Line up
the holes on the seat rails to the holes on the seat
extension tubes.
3. Insert the U-clips and depress until fully locked onto the
seat rail.
4. Slide the hook and loop upholstery extension under the seat
upholstery on the wheelchair to adhere to the matching hook
and loop strip.
NOTE:
Ensure the extender is locked in place and secure
before putting to use.
ADJUSTING LENGTH OF FOOTREST/LEGREST
D
10
1. Turn the front rigging to the side (open
footplate is perpendicular to wheelchair).
2. Install the front rigging hinge plates onto
the hinge pins on the wheelchair frame
(Fig. B).
3. Push the front rigging towards the inside
of the wheelchair until it locks into place.
An audible click will be heard.
Anti-Tippers will come preinstalled on your K4
Deluxe out of the box.
1. To adjust the height of the anti-tippers.
Squeeze and push the red buttons forward.
With your other hand, you will be able to
NOTE:
When caregiver is adjusting length of
footrests or legrests, user should be sitting in
wheelchair with feet on
the footplates.
1. Flip up the locking clamp around the
support assembly (Fig. D).
