Venmar 41300 Guide D'installation Et D'utilisation

The illustrations in this document are generic; your control appearance may be slightly different from the ones shown.
Electrical wiring must be done by qualified personnel in accordance with all applicable codes and standards.
Before connecting wires, unplug the unit or switch power off at service panel and lock service disconnecting
means to prevent power from being switched on accidentally. Always wear safety glasses and gloves while
performing these instructions.
INSTALLATION

Unplug the ventilation unit.

Cut a 2 / " x 1¾" hole in a wall, at a
7
8
convenient location for the control.
Route a cable (type 22/4) for the
control from the unit to this hole. See
figure at right.

Temporarily place the control over the
hole and mark both mounting screw hole
positions.

Remove the control, drill both screw
holes (3/16" Ø) in wall and insert the wall
anchors (included).

Strip the end of the cable to access the 4 wires (about 3"). Strip the
end of each wire (about 1/4"). Connect the wires to the terminals,
regardless of the wire color. Note which wire color has been
chosen for each terminal. See illustration below.
VC0233

Mount the control to the wall.
I U
NSTALLATION AND
EE . 41300 V
VÄN PART NO
READ AND SAVE THESE INSTRUCTIONS
Ø 3/16", typ.
VC0210A
12V
LED
OVR
Gnd
VC0211
G 20-40-60 C
SER UIDE FOR
ENMAR PART NO
WARNING
!

Depending on the type of fresh air system installed,
perform
connector of the unit as per one of the four models illustrated
hereafter. For more details, refer to the installation manual of the
ventilation unit.
NOTE: To avoid miswiring, refer to the notes taken at step
to match the wire color with the right terminal.
VC0234
VC0238
VC0237
VC0239

Plug the ventilation unit and test the wall control.
HOW TO USE THE CONTROL
VC0212
ONTROL
. 41400
the electrical connection
Remote 6 & 7 positions terminals
Remote 10 positions terminal
Remote 4 & 6 positions terminals
On-board terminal
The main button works following this
sequence:
• Click 1 = 20 min
• Click 2 = 40 min
• Click 3 = 60 min
• Click 4 = OFF
• and so on
The indicator lights up as per the selected
duration and the system exchanges air at
MAX speed.
to the terminal

12V
LED
OVR
Gnd
23849 rev. 01
