NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
7. OPERATION
A.) VENTILATION
RISK OF INDOOR AIR POLLUTION/USE HEATER ONLY IN WELL VENTILATED AREAS.
Provide at least a three-square foot (2,800 sq. cm.) opening of fresh outside air for each 100,000 BTU/Hr.
of heater rating.
B.) OPERATION
TO START HEATER
1. Fill fuel tank with fuel.
ignition delay or failure.
2. Attach fuel cap.
3. Plug power cord of heater into three-prong, grounded extension cord.
Extension cord must be at least six feet long.
Extension Cord Wire Size Requirements
switch to "ON" position, power indicator lamp and room temp. display will light and heater will start.
NOTE: Room Temp. display indicates as following,
If heater does not start, the thermostat setting may be too low, turn "THERMOSTAT CONTROL
Knob" to higher position to start heater. If heater still does not start, turn operating switch to "OFF"
page 13.

INDICATOR LAMP

ROOM TEMP. DISPLAY
THERMOSTAT CONTROL KNOB
NOTICE : The major electrical components of this heater are protected by a safety fuse mounted to the PCB board.
If your heater fails to start, check this fuse first and replace as necessary. You should also check your
power source to insure that proper voltage and frequency are being supplied to the heater.
℉
℉ ℉
℉
Figure 4. CONTROL PARTS
6
℉ ℃
℉ ℉
operating
OPERATING SWITCH
