Pizza pocket location
Assembly Instructions
1. Insert three hooks on part "A" into their corresponding slots
on part "B". Ensure the hooks fit into the side opposite to the
upper lip.
A
2. Assemble parts A and B at angle 90°.
NOTE: Do not exceed angle more than 90°.
3. Place the assembly onto the studs on the liner wall.
W11189663A
PIZZA POCKET ASSEMBLY
Upper lip
B
A
90
o
B
Application Overview
©2017 All rights reserved.
Closed position
Open position
Pizza in place (intended use)
12/17
