4 Setting into Operation

4.1 Connecting the receiver

1) Connect the receiver to the following unit (e . g .
amplifier, mixer) . For this purpose, two audio
outputs are provided:
– MIC OUT (10) as an XLR jack, balanced to
connect a microphone input
– LINE OUT (11) as a 6 .3 mm jack, unbal . to
connect an input with line level; use the con-
nection cable provided
2) Connect the power supply unit provided to the
power supply jack (8) and to a mains socket
(230 V/ 50 Hz) .
4.2 Inserting the batteries into the
transmitter
For operating the wireless microphone and the
pocket transmitter, two 1 .5 V batteries of size AA
are required .
•
Always insert (rechargeable) batteries of the
same type and always replace all of them .
•
If the transmitter is not in use for a longer period
of time, always remove the batteries to prevent
damage to the unit in case of battery leakage!
Never put batteries in the household
waste . Always dispose of the batteries in
accordance with local regulations .

4.2.1 Wireless microphone

To open the battery compartment (17), press the
arrow of the battery compartment cover and push
the cover downwards .
Insert the batteries with the positive and neg-
ative poles as indicated in the compartment, then
replace the cover .

4.2.2 Pocket transmitter

To open the battery compartment (28), press the
arrow of the battery compartment cover (24) and
push the cover downwards .
Insert the batteries with the positive and neg-
ative poles as indicated in fig . 3, then replace the
cover .
for TXS-611SET and TXS-616SET only
1
for TXS-636SET only
2
12
1
2
4.3 Connecting and attaching
the tie clip microphone
and the pocket transmitter
1) Connect the plug of the tie clip microphone
to the 3 .5 mm jack (25) of the transmitter . To
prevent accidental disconnection, secure the
plug with the cap nut .
2) Attach the tie clip microphone to your clothes,
as close to your mouth as possible .
3) After all adjustments have been made (chap-
ters 4 .4 and 5), use the clip (26) to attach the
transmitter to your clothes (e . g . belt or waist-
band) .

4.4 Adjusting the transmission channel

To adjust a free transmission channel on the re-
ceiver, either use the automatic scan function or
adjust the channel manually . Then simply press
a button to adjust the wireless microphone
the pocket transmitter
IR signal .
1) Switch on the receiver with the POWER switch
(9) . To switch on the pocket transmitter, set the
switch (21) to the position ON . To switch on the
wireless microphone, set the switch (16) to the
upper position . After switching on, the corre-
sponding display (3, 14, 22) lights up .
2) To automatically scan a free channel, press the
button SELECT (2) briefly . To indicate the scan,
one segment of the numerical display element
starts moving around on the display (3):
After a while, the display shows the number of
the channel found . The correspond ing frequen-
cies can be found in the tables on page 40 .
3) To manually adjust a specific transmission
frequency, find the corresponding channel num-
ber in the tables on page 40 . To adjust the
channel number, keep the button SELECT (2)
pressed until the units digit on the display (3)
starts flashing . Press the button briefly to adjust
the units digit . Keep the button pressed again
until the tens digit on the display starts flash-
ing . Press the button briefly to adjust the tens
digit . A few seconds after you have pressed the
button for the last time, the the digit will stop
flashing to indicate that the channel adjustment
has been stored .
