S+S Regeltechnik PREMASGARD 711 Serie Notice D'instruction page 12

G
®
PREMASGARD
Mounting diagram
(A)
2-wire
PREMASGARD
connection
(without automatic
zero point calibration)
- -
230V AC
+
24V DC
1 2 3
Load resistance diagram
2-wire connection
Load resistance diagram
800
700
600
500
400
300
250
200
50
10 15 20
Operating voltage (V DC)
711x
(B)
® 3-wire
711x - I
connection
(with automatic
zero point calibration)
230V AC
PLC
+
Working
resistance
24V AC/DC
®
PREMASGARD 711x - I
Admissible
range
25 30 35 36 40
(C)
®
PREMASGARD 711x - I
PLC
PC
1 2 3 4
Load resistance diagram
3-wire connection
Load resistance diagram
500
450
400
300
Admissible
range
200
100
25
10 15 20
Operating voltage (V DC)
12
TYPES OF MONITORING
(A) Below-atmospheric pressure:
P1 (+) is not connected
but open against atmosphere
P2 (–) connected to inside of duct
(B) Filter:
P1 (+) connected upstream of filter
P2 (–) connected downstream of filter
(C) Ventilator:
P1 (+) connected downstream of ventilator
P2 ( – ) connected upstream of ventilator
Pressure connections at the pressure
switch are marked with
P1 (+) for higher pressure and
P2 (–) for lower pressure.
3-wire
PREMASGARD
connection
230V AC
24V AC/DC
1 2 3 4
®
PREMASGARD 711x - I
25 30 35 36 40
Rev. Data - V41
® 711x - U
PLC
PC
