2.3 To connect the hose
EN
● The hose is attached to the trigger handle on delivery.
Follow the instructions if it comes loose.
SV
1
Move the nut on the hose away from the end of
the hose.
NO
2
Put the end of the hose tightly into the hose
connector.
PL
3
Tighten the nut on the connector. Do not tighten
too much.
DE
2.4 To fit and adjust the straps
FI
1
Attach the 4 hooks on the straps to the tank.
(Figure 5)
FR
2
Adjust the straps to applicable length.
NL
3
Operation
3.1
To fill the tank
Warning! Remove the battery and close the bat-
tery lid before you fill the tank.
Warning! Before chemicals are used, do a check of
all the information on the label on the original container
and follow the instructions.
Warning! Do not spray liquid with a consistency
thicker than water. Thick liquids cannot be sprayed
properly.
Caution! Do not fill the spray tank too much.
Note! The strainer prevents debris from causing block-
age and damage to the tank. It can be removed when
you clean or funnel liquids. Always put the strainer back
before you use the product. (Figure 6)
1
Remove the lid of the tank.
2
Fill the tank with the applicable quantity of water.
3
Measure the recommended quantity of chemicals
and carefully put it into the tank.
4
Put back the lid on the tank.
Note! The spray liquid can also be mixed in advance and
then added to the tank using a funnel.
12
3.2 To attach and remove the battery
Caution! Make sure that the battery is correctly
attached. If the battery become loose, it can cause
personal injury.
Caution! Do not force the battery in position. If it is
not easy to attach, it is not correctly aligned.
3.2.1 To attach the battery
1
Push the catch and open the battery cover.
(Figure 7)
2
Align the battery to the slots in the casing.
(Figure 8)
3
Push the battery until a clicks is heard.
3.2.2 To remove the battery
1
Push the button on the front of the battery.
2
Pull the battery out from the battery port.
3
Close the battery cover.
3.3 To operate the product
Caution! Before use, do a check that the spray
head is firmly fixed on the handle. If necessary use pliers
to tighten the spray head connection to the handle.
The product have 2 different spray modes.
● Low pressure mode (I)
● High pressure mode (II)
1
Set the power switch to (I) or (II) to start the
product.
2
Push the trigger to spray.
Note! Keep a safe distance from the object being sprayed
to avoid contact with chemicals.
3
Set the power switch to (0) to stop the product.
Note! Remove the liquid and clean the spray tank after
use.
Note! After use, wash your hands and any parts that has
come into contact with chemicals.
