Simons Voss Technologies Digital SmartHandle AX Guide Abrégé page 14

9. Installing the fitting
31
Area
S
S
S
S
S
S
S
S
M
M
M
M
M
M
M
M
L
L
L
L
L
L
L
L
XL
14 / 60
Door thickness (mm)
40 - 42
40 - 42
43 - 47
43 - 47
48 - 52
48 - 52
53 - 57
58 - 61
60 - 62
60 - 62
63 - 67
63 - 67
68 - 72
68 - 72
73 - 77
78 - 81
80 - 82
80 - 82
83 - 87
83 - 87
88 - 92
88 - 92
93 - 97
98 - 101
100 - 184
Digital SmartHandle AX Metal frame
Spindle length (mm)
94
104
94
104
94
104
104
104
114
124
114
124
114
124
124
124
134
144
134
144
134
144
144
144
O-ring is 30–35 mm from the cut end of the spindle.
Ring position
3
5
2
4
1
3
2
1
3
5
2
4
1
3
2
1
3
5
2
4
1
3
2
1
