SAVE THESE INSTRUCTIONS
INTRODUCTION
This manual provides information necessary to operate the SMARTDOSE® EVOLUTION
used with CGA 870 post-valve cylinder [see Fig. A] at home or away from home to provide your specific oxygen requirements. It requires two (2) 1.5
volt AA alkaline batteries for operation.
PURPOSE:
The SMARTDOSE® EVOLUTION
conserver. It is designed for use with a cylinder as an ambulatory oxygen system and is capable of delivering a specific amount of supplemental
oxygen at the optimal point in the breathing cycle. The SMARTDOSE® EVOLUTION
mizing the beneficial effects and eliminating unnecessary oxygen waste.
FUNCTION:
When we breathe, approximately one-third of the time is spent inhaling and two-thirds exhaling. As a result, oxygen delivered by continuous flow is
wasted during exhalation. By eliminating oxygen flow during exhalation, a two-thirds savings possible. Additionally, the oxygen available during the
very first part of inhalation contributes most to meeting oxygen needs. The SMARTDOSE® EVOLUTION
advantage of these facts to provide maximum efficiency in the delivery of oxygen. This device is designed to be an integral component of a light-
weight, long-lasting supplemental ambulatory oxygen system.
8
OM-975 electronic oxygen conserver includes a combination of a low-pressure regulator and an oxygen
™
OM-975 electronic oxygen conserver. This conserver can be
™
OM-975 increases the efficiency in the delivery of oxygen, maxi-
™
OM-975 electronic oxygen conserver takes
™
Toggle
Parallel Holes on the
Post Valve
FIGURE A
Post-Valve Cylinder
