Alarm memory
When SW1-5 is set to Remote on, alarms that occurred during
the night mode are stored in the detector memory. They are
indicated by flashing red LED when the unit switches to day
mode (walk test disabled). The memory is cleared when the
detector switches back to the night mode.
Note:
Set SW1-6 to Off to prevent showing the alarm memory
on the LEDs. See "SW1-6: LEDs" on page 6.
LEDs and outputs
To enable LEDs functionality, set SW1-6 to On, otherwise
LEDs are disabled in any condition. See "SW1-6: LEDs" on
page 6 for more details.
Table 6: LEDs and outputs
Status
Red
Yellow
LED
LED
Start up
Low voltage
PIR intruder
alarm
Microwave
intruder alarm
Dual motion
intruder alarm
Dual Alarm
Memory
AM alarm
Technical fault
Continuously ON
Normal blinking (1 Hz)
Specifications
Detector technology
Range
Viewing angle
PIR optics
Microwave frequency
Max microwave output at 1 m
Memory function
Input power
Peak-to-peak ripple immunity
Detector start-up time
Current consumption
Mounting height
Target speed range
Alarm (NC) / Tamper relay
characteristic
Fault relay characteristic
Alarm time
Operating temperature
P/N 146667999-1 (ML) • REV B • ISS 13OCT17
To reset
Alarm
Fault
relay
relay
Closed
Closed
Automatically
after 60 s
Open
Open
Apply correct
voltage
Closed
Closed
Closed
Closed
Open
Closed
Automatically
after 3 s
Closed
Closed
Switch to the
night mode
Depends
Open
Depends on
on SW2-4
SW2-3
Closed
Open
Successful walk
test
Dual+AM
10, 12, 14, 16 m selectable via
SW1-1 and SW1-2
78 degrees
9 high-density mirror curtains
5.8 GHz
0.003 μW/cm²
Yes
9 to 15 V
(12 V nominal)
2 V (at 12 V )
60 s
10 to 22 mA (11 mA nom.)
2.0 to 3.0 m (6.60 to 9.84 ft.)
0.2 to 3.0 m/s (8 in./s to 10 ft./s)
80 mA 30 V , Form A
80 mA 30 V , Form A
3 s
−10 to +55°C (14 to 130°F)
Relative humidity
Weight
Dimensions (H x W x D)
IP/IK rating
Pry-off tamper
Regulatory information
Manufacturer
UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Warnings and
These products are intended for sale to, and
Disclaimers
installation by, an experienced security
professional. UTC Fire & Security cannot provide
any assurance that any person or entity buying its
products, including any "authorized dealer," is
properly trained or experienced to correctly install
security related products.
For more information on product warnings, refer
to www.utcfssecurityproducts.eu/productwarning/
or scan the code.
Certification
European Union
UTC Fire & Security hereby declares that this
directives
device is in compliance with the applicable
requirements and provisions of all applicable
rules and regulations, including but not limited to
the Directive 2014/53/EU. For more information
see: www.utcfssecurityproducts.eu
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
www.utcfssecurityproducts.eu/recycle/
Contact information
www.utcfireandsecurity.com or www.interlogix.com.
For customer support, see www.utcfssecurityproducts.eu
DA: Installationsvejledning
Beskrivelse
DDV1016AM er en kombi detektor med antimask (AM).
Den omfatter den patentbeskyttede PIR-spejloptikteknologi
med den patentbeskyttede Range Controlled Radar-teknologi.
Installationsvejledning
Se figur 1.
Detektoren er beregnet til vægophæng men kan også
monteres i loftet med et monteringsbeslag.
95% max., noncondensing
120 g
126 × 63 × 50 mm
IP30 IK04
Yes
