WARNING: ALWAYS UNPLUG THE TREADMILL
FROM THE ELECTRICAL OUTLET BEFORE
CLEANING OR SERVICING THE UNIT.
EXPLODED VIEW
16
PARTS LIST
No.
Description
01
Front cross pipe welding
02
Supporting tube set
03
middle supporting tube set
04
Limited Iron Plate
05
left Sticks
06
Right Sticks
07
Front roller
08
Drive belt
09
Rear roller
10
Running borad
11
Running belt
12
upper motor cover
13
Lower motor cover
14
Moving wheels
15
Front foot pad
16
Back foot pad
17
motor
18
Shock absorber for motor
19
Controller board
20
Main console board
21
Screw M6*35
Unit qty
1
2
1
2
1
1
1
1
1
1
1
1
1
2
2
2
1
2
1
1
2
