FRANÇAIS Sonde intelligente en version température. Conçu pour contrôler la qualité de l’air intérieur (QAI) en créant des systèmes de ventilation à demande contrôlée sans avoir besoin d’installer des commandes intermédiaires. SÉCURITÉ L’installation doit être réalisée par un installateur qualifié. Vérifier que l’insta- llation est conforme aux règlements mécaniques et électriques en vigueur dans le pays.
Page 4
INSTALLATION Le dispositif doit être installé à l’abri des projections d’eau (IP30), sur une sur- face plane, en utilisant tous les points de fixation (voir Fig.4) et nécessite une installation de type X. La hauteur d’installation recommandée est comprise entre 1,5 et 1,8 m.
Page 5
à ce type de communications. S&P ne fournit pas de logiciel spécifique à cet effet. Les informations fournies dans la carte Modbus permet- tent d’établir une communication correcte entre le AIRSENS TEMP / RF TEMP et le logiciel de configuration.
Page 6
Type de connecteur: câblage D0 – D1 – Commun CALIBRATION / RESET La première fois que la sonde AIRSENS TEMP est mise sous-tension ou après avoir réalisé un reset, elle nécessite env. 15mn pour effectuer un étalonnage et stabiliser la première lecture de température.
Page 7
Plage de mesure TEMP ............ 18-50ºC Précision TEMP ............ ± 0,4ºC Temps de démarrage et d’étalonnage TEMP ............ 30 secondes (15 minutes pour stabiliser la première lecture de température lors de l’alimentation) Dim. boîtiers [hauteur x largeur x prof.] ... 89 x 122 x 26 mm ENVIRONNEMENT D’UTILISATION ET AUTRES CARACTERISTIQUES Température ambiante ......
Page 8
MISE HORS SERVICE ET RECYCLAGE La norme de la CEE et l’engagement que nous devons maintenir envers les futures générations nous obligent à recycler le matériel; nous vous prions de ne pas oublier de déposer tous les éléments restants de l’emballage dans les containers correspondants de re- cyclage.
Page 11
ENGLISH Intelligent sensor in temperature version. Designed to create direct demand control ventilation systems based on Indoor Air Quality reading. SECURITY Installation must be carried out by a qualified professional. Make sure that the installation complies with mechanical and electrical national regulations. Once in service, the appliance must comply with corresponding Directives.
Page 12
In the case of an installation where cabling is outdoors, it must be installed inside a cable ducting system with IP4X protection degree classified as “cable ducting with access cover that can only be opened with a tool” according to UNE-EN 50.085-1: Cable trunking systems and cabling ducting systems for electrical in- stallations- Part 1: General requirements.
Page 13
For visualization, modification and control via Modbus it will be necessary to have software suitable for this kind of communication. S&P will not provide specific software for this purpose. The information provided on the Modbus registers al- lows establishing a correct communication between AIRSENS TEMP / RF TEMP and configuration software chosen.
Page 14
Connector type: wiring D0 – D1 – Common CALIBRATION / RESET The first time the AIRSENS TEMP probe is powered on or after performing a reset, it requires approximately 15 minutes to perform a calibration and stabilize the first temperature reading.
Page 15
Measurement range TEMP ............ 18-50ºC Accuracy TEMP ............ ± 0,4ºC Warm-up time TEMP ............ 30 seconds (15 minutes to stabilize first temperature reading when power supply) Case dimensions [height x width x deep.] .. 89 x 122 x 26 mm USAGE ENVIRONMENT AND OTHER CHARACTERISTICS Ambient temperature ......
Page 17
MF4: Modbus control Access to all operating modes and parameters via Modbus communications (see Fig.3). 1 2 3 4 The microswitches marked 5 and 6 must be set to ON. Note: If other switch combination is chosen, LED diffuser is switched off and digital/analo- gue signals are inoperative.
Page 18
Fig. 3: Modbus registers / Table des registres Modbus Output Coils (Read) Register Output Coil Data type Range Default Comments Output analogue signal 0-10V 0 : OFF Invertir Set Point / 2-10V change and have an 1 : ON inverse response Reboot Factory 0 : OFF Modbus registers pass to settings...
Page 19
Input registers (Read) Register Discrete input Data type Range Default Comments 30001 SetPoint 16bits 0-100 P1 potentiometer position (%) P1 potentiometer value 30002 SetPoint Value 16bits 0-2000 Temperature sensor value (°C) (Example: 213 = 21,3°C) Light guide 30003 16bits 0-100 P2 potentiometer position (%) intensity Analogue output (Vdc)
Page 20
Holding registers (Read and write) Register Discrete input Data type Range Default Comments 40001 Addressing 16bits 1-247 Channel 48 : 4800 96 : 9600 40002 Baud Rate 16bits Bus speed 192 : 19200 384 : 38400 0 : EVEN 40003 Parity 16bits 1 : ODD Parity 2 : Non parity Set Point Temperature SetPoint...
Page 21
Fig.4: Dimensions Fig.5: Front cover dismounting / Démontage du couvercle...
Page 22
Fig.6: Cable retention / Amarrage des câbles électriques...
Page 24
