Replacing the Ax-
ial Fan
Replacing the Ra-
dial Fan
12
(5)
(6)
(7) (8) (9)
(2)
(1)
(1)
Disconnect 2 plugs (6, 9)
2
Disconnect the fan cable (7, 8)
3
Remove inductance bridge (5)
4
Remove 2 TX 25 screws (1)
1
Remove fan
2
Insert the new fan so that the connec-
3
tion cable (2) is positioned on the side
shown.
Secure fan with 2 TX 25 screws (1)
4
(1)
tightening torque: 0.8 Nm / 0.6 ft lb.
Remove 2 screws (1)
1
Remove fan
2
Insert new fan
3
NOTE! When securing the fan,
make sure that the rubber gasket
is up against the heat sink.
IMPORTANT! Do not pinch the fan cable
between the fan and the housing.
Secure fan with 2 screws (1)
4
tightening torque: 3 Nm / 2.2 ft lb.
(1)
