OPERATING INSTRUCTIONS
CONTROL PANEL
1. Swing and wireless connect button:
• Press to start the auto swing feature. When auto
swing is activated, press again to stop the louver
at the desired angle.
• Press and hold for three seconds to start using
the wireless connect feature.
2. Fan button:
• Press to select fan speed. Light will indicate
current speed.
• Press and hold for 3 seconds to turn the
continuous fan on or off.
3. Timer button: Press to start the automatic timer.
Light will indicate whether a timer is set.
4. Temperature control buttons:
• Used to set the temperature and timer.
• Press and hold both temperature control buttons
for three seconds to change the temperature
display from °C to °F.
5. LED display:
• Shows the set temperature in °C or °F.
• Shows the timer settings.
• While on dry mode, shows the relative humidity.
• When on fan mode, shows the room
temperature.
6. Sleep and filter button:
• Press to start the sleep feature.
• The filter light will illuminate after 250 hours of
use as a reminder to clean the filter; to reset the
filter after cleaning, press and hold the sleep
button for three seconds.
7. Mode button: Press to select the desired mode.
Modes will cycle in sequence with each press
of the button; auto, cool, dry, fan. Light will
indicate current mode.
8. Power button: Press to turn the appliance on or
off.
1
2
3
3sec
3sec
5
6
7
8
4
3sec
OPERATING MODES
Cool Mode
Choose cool mode to set the cooling function.
• Use the temperature control buttons to choose
the desired temperature.
• Use the fan button to choose the desired fan
speed.
• The temperature can be set within a range of 17
- 30°C (62 - 86°F).
• The exhaust hose should be installed during cool
mode to ensure the best results.
Dry Mode
Choose dry mode to remove excess moisture from
the air. Water will condense inside the appliance
and drain out the back.
• The humidity level and fan speed will be
automatically set and cannot be modified in dry
mode.
• The exhaust hose does not need to be installed
during dry mode.
• It may be necessary to install the continuous
drain hose during dry mode to remove excess
water.
OPERATING MODES
Fan Mode
Fan mode can be used to run the fan without
engaging the cooling or dehumidifying functions.
• Press the fan button to choose the desired fan
speed.
• The exhaust hose does not need to be installed
during fan mode.
• In cooling or dry mode, press and hold the
fan button for 3 seconds to set the fan to run
continuously. Press and hold the fan button for 3
seconds to disengage the continuous fan. During
normal operation the fan will turn on and off
with the compressor.
Auto Mode
Auto mode is a pre-set factory program that
automatically defines the mode (cool or fan) and
fan speed based on the set temperature and the
ambient temperature. The exhaust hose should be
installed during auto mode.
13
