Reconnect the cable to the movement
14
on this clock face (limit its length with the
cable clip).
Before replacing the clock's face on the
15
grommet side, proceed with the clock's
internal cabling. Refer to the following
chapters of this manual according to your
model.
If
subsequent
required, remove only the clock's
face on the grommet side.
Access
to
the
requires removal of the side opposite
the grommet.
Once the clock has been wired, clean the
16
seal on the clock's face on the grommet
side, then apply silicone oil on it.
Realign this clock face, then reconnect
17
the cable from the terminal block (or the
electronic card) to the movement situated
on the disassembled face.
Limit the length of the cable by running
18
it through the cable clip in order to avoid
shading in the case of the lighting option
(contact of the cable with the dial once the
clock is closed).
Close the clock by replacing the
19
disassembled face back in its original
position.
Tighten the four cover screws (1.2 Nm) on
20
the newly reassembled clock face.
Replace and tighten the air inlet screw
21
(15 Nm) located beneath the bracket arm.
2.2.1.2 Mounting with IP65 sealing plate (optional)
Unscrew and remove the air inlet screw
1
located beneath the bracket arm.
(6 mm Allen key, tightening torque: 15 Nm)
Partially unscrew the four cover screws
2
on one clock's face. (3 mm Allen key,
tightening torque: 1.2 Nm)
Carefully slide open and partially separate
3
the face to access the clock's internal
cabling.
Disconnect the cable connected to the
4
movement on both clock faces.
Remove the first clock face completely
5
and place it on a straight, clean and
uncluttered work surface.
Partially unscrew the four cover screws
6
of the second face, then remove this
face and place it on a straight, clean and
uncluttered work surface.
maintenance
is
battery
(optional)
A2
B2
(mm)
P750
A2
153
B2
423
C2
216
D2
540
E2
70
F2
100
G2
150
H2
74
I2
34
X8
EN
I2
H2
D2
F2
C2
P760
P780
150
160
470
580
216
218
640
840
70
70
100
100
150
150
74
74
34
34
31
