Maytag MZF34X18FW Guide De Démarrage Rapide

OPERATING INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS,
located in your appliance's Owner's Manual, before operating this appliance.
IMPORTANT: Before operating this appliance, make sure it has been properly installed according to the appliance's
Owner's Manual.
The temperature control is located at the front of the freezer compartment.
For your convenience, the temperature control is preset at the factory. When you first install your freezer, check that the
control is still set to the recommended setting as shown.
IMPORTANT:
■ The recommended setting is designed to maintain the temperature at or near 0°F (-17.8°C) under normal operating
conditions.
■ Allow the freezer to cool 6 to 8 hours before filling with frozen food.
■ When the freezer is first started, the compressor will run constantly until the freezer is cooled. It may take up to
6 or 8 hours (or longer), depending on room temperature and the number of times the freezer door is opened. After the
freezer is cooled, the compressor will turn on and off as needed to keep the freezer at the proper temperature.
■ The outside of your freezer may feel warm. This is normal. The freezer's design and main function is to remove heat
from packages and air space inside the freezer. The heat is transferred to the room air, making the outside of the
freezer feel warm.
FAST FREEZE (on some models)
Use this feature before adding large amounts of unfrozen food. For the best food quality, do not exceed
3 lbs. (1,361 g) per cu. ft. (28.32 L) of freezer space.
To activate Fast Freeze, press Temp Setting until all the indicator light positions are illuminated simultaneously.
The freezer will remain in the Fast Freeze setting for 24 hours after the extra-low temperature is reached. Once the time
has expired, the freezer will return to the previous temperature setting. Fast Freeze may be manually turned off by pressing
Temp Setting to select the desired temperature setting from the snowflake on the left (least cold) to the snowflake on the
right (coldest).
COOLING ON/OFF
Your freezer will not cool when cooling is turned off.
To turn cooling off, press and hold Temp Setting for 3 seconds. In the off condition, none of the lights on the control panel
will be illuminated. The main freezer light bulb will still operate.
To turn cooling on, press and hold Temp Setting for 3 seconds. When cooling is on, the control panel lights will be
illuminated.
ADJUSTING CONTROL
If you need to adjust the temperature in the freezer compartment, press Temp Setting to display the desired temperature
setting from Cold to Coldest.
NOTE: Except when starting the freezer, do not adjust the control more than one setting at a time. Wait 24 hours between
adjustments for the temperature to stabilize.
W11395572B
Upright Freezer Quick Start Guide
Recommended setting "Colder"
Freezer Features
The freezer you have purchased may have some or all of the items listed. The locations of the features
may not match those of your model.
FREEZER SHELVES
Store similar foods together and adjust the shelves to fit
different heights. This reduces the time the freezer door is
open and saves energy.
To Remove and Replace a Shelf:
1. Remove the shelf by lifting straight up and pulling the
shelf out.
2. Replace the shelf by lowering the shelf onto the supports
on the side wall.
STORAGE GATE (on some models)
To Remove the Storage Gate:
1. Lift the top of the gate up and out of the supports.
2. Return the gate to original position. Lower the gate into the supports.
Online Ordering Information
For detailed installation instruction and maintenance information, winter storage, and transportation
tips, please see the Owner's Manual included with your appliance.
For information on any of the following items, the full cycle guide, warranty, detailed product
dimensions, or for complete instructions for use and installation, please visit
https://www.maytag.com/owners, or in Canada https://www.maytag.ca/owners. This may save
you the cost of a service call.
However, if you need to contact us, use the information listed below for the appropriate region.
United States:
1–800–344–1274
Maytag Brand Appliances
Customer eXperience Center
553 Benson Road
Benton Harbor, MI 49022–2692
SAVE THESE INSTRUCTIONS
Canada:
1–800–688–2002
Maytag Brand Appliances
Customer eXperience Centre
200–6750 Century Ave.
Mississauga, Ontario L5N 0B7
