5. Typical installation
Example of an open-outlet installation with special tap
Remote control with wall bracket
Shorten cable
if necessary
(approx. 600)
Dimensions in mm
Example of a closed-outlet installation
125
Depth 19
100
G ⅜
Depth 108
177 ≥70
19
75
