ENGLISH
-
Replace litter: press and hold "Replace litter" for 2 s to start emptying the waste tank.
-
Self-cleaning: press "Auto" to activate the self-cleaning mode.
-
Deodorisation: press "Deodorisation" to eliminate unpleasant odours for 30 s.
-
Connect: press and hold "Auto" for 2 s to connect the device to the application.
-
Levelling: press and hold "Deodorisation" for 2 s to spread the litter and level.
-
Replace waste bag: Press and hold "Clean" for 2 s to adjust the waste tank to the angle of
the waste bag.
-
Child lock: press and hold "Auto" and "Deodorisation" for 2 s to lock or unlock the litter
box.
-
Infrared sensor: press and hold "Clean" and "Replace litter" for 2 s to switch on or off the
infrared sensor (it is switched off by default).
Adding litter
1. Add an adequate amount of litter from the inlet with a shovel using the barrel fill line as a
reference. Fig. 5
1.1 The amount of litter must not exceed the maximum line.
1.2 The amount of litter should not be below the minimum line.
2. The amount of litter added should never exceed the MAX fill line marked on the grey part
of the barrel to avoid overfilling and spillage.
It is recommended to keep the amount of litter at the MIN fill line (never below), as this
will prevent the litter from sticking to the bottom.
3. Levelling: After adding litter (≥ 0.6kg), press and hold the deodorisation icon for 2
seconds. Then, follow the instructions below.
4. Litter surface calibration: to spread the litter evenly, we can adjust the inclination of the
litter surface through the application.
-
Open the application, enter the settings page, and click on "Litter surface calibration".
-
The default value of the litter surface calibration is 3, but it can be adjusted from 0 to 6.
From the entrance of the litter box, if you notice that the level on the right side of the litter
surface is lower, increase the value, and the same for the level on the left side.
-
After increasing or decreasing the value by 1 point, press and hold the deodorising icon
for 2 s to make the barrel rotate slightly once and spread the litter. Then make sure that
the surface of the litter is completely level.
Warning:
-
The first time it is used, you can mix the new litter with the old litter to help the cats
adjust to the new litter box.
-
It is recommended that the amount of biodegradable and mixed litter should not exceed
3 kg, that the amount of mineral litter should not exceed 4.5 kg, and that the number of
other types of litter should be in between.
-
After adding the litter, if it is not spread and levelled, the litter box will activate the anti-
gravity protection lock (no cleaning or litter replacement). It will be necessary to manually
44
PUMBA 8000 CLEANKITTY SMART
