THE EYEPIECE
Your telescope comes with a 10mm and 20mm Kellner
eyepieces. Additional eyepieces can be purchased to
increase or decrease the magnifi cation to your desired level.
1. Loosen the set screws on the open end of the star
diagonal.
2. Insert the silver barrel of the 20mm eyepiece into the
star diagonal.
3. Tighten the setscrews to secure the eyepiece
4. To see the sharpest image possible, focus by looking
through the eyepiece and slowly turning the focusing
knobs until the image comes into sharp focus.
THE STARPOINTER FINDERSCOPE
Your telescope comes with a StarPointer fi nderscope
that you will use as a sighting tool when aiming the telescope
at a target. Your StarPointer fi nderscope is shipped with a
clear plastic tab inserted between the battery and the contact
to prevent the battery from accidentally being discharged in
shipment. Pull this tab out before using your fi nderscope.
To install the fi nderscope:
1. Slide the fi nderscope bracket into the dovetail slot on
the telescope tube near the focuser. The large window
on the fi nder should be facing the front of the telescope.
2. Secure the bracket by tightening the setscrew on the
dovetail slot.
BATTERY ACCESS INSTRUCTIONS
The StarPointer fi nderscope is powered by a long life 3V lithium battery (#CR2032) located directly under the
StarPointer's front end.
To access the battery compartment, turn the StarPointer upside down. Using a Phillips head screwdriver, loosen the
screw and lift up the battery cover. When replacing the battery, make sure to install the new battery with its positive
terminal (+) facing outward. If the telescope will not be in use for a long period of time, it is recommended to remove the
battery from the StarPointer.
WARNING: KEEP BATTERIES OUT OF REACH OF CHILDREN.
• Examine devices and make sure the battery compartment is correctly secured, e.g. that the screw or other mechanical
fastener is tightened.
• Do not use if compartment is not secure.
• Dispose of used button batteries immediately and safely. Flat batteries can still be dangerous.
• Tell others about the risk associated with button batteries and how to keep their children safe.
MOVING THE TELESCOPE
The Omni AZ mount has slip clutches in both axes. To make large movements with the telescope, simply hold the optical
tube and push it in the desired direction. To make fi ne adjustments or to track celestial objects, turn both slow motion knobs.
5
