Tiny Love 3 IN 1 ROCKER-NAPPER Mode D'emploi page 5

Using the 3 in 1 Rocker–Napper
Securing baby in Rocker–Napper
1. Turn the Toy Arm away and place baby in the seat. Position the
safety restraint belt between the baby's legs.
2. Fasten the two ends of the safety restraint belt to their
corresponding buckles until you hear a click. Make sure the safety
belt is securely attached by gently pulling it away from your baby.
3. Adjust the Toy Arm to an appropriate angle for your baby. Turn on
the vibration unit and the activity center if desired.
Adjusting the reclining positions
1. There are 3 reclining positions: Reclined, Middle and Flat.
1
2. To adjust the Rocker/Napper to the desired position, pull the
reclining handle which is located under the head of the Main Body
(Fig. 16).
Note: The Flat position can be used when baby falls asleep.
The Middle reclined position is recommended for babies with relux.
Always support the back of the rocker with your hand when adjusting the
angle of recline.
3 in 1 modes of use:
1
1. Rock & Play - the front and back legs must be folded inwards.
2. Napper – adjust the legs as follows:
front leg must be open
back leg must be folded inwards
3. Stable seat – adjusts the legs as follows:
back leg must be open
front leg must be folded inwards
Operating and using the activity center
There are two methods of changing the position of the activity center:
Moving the arm – for easy parental access or for baby's needs
Changing the activity center's angle – to adjusts to baby's position
2 3
2 3
For more developmental information and playing tips, please visit:
www.tinylove.com
© 2012. All rights reserved, Tiny Love Ltd.
There are two operating buttons, one for volume and one for music.
1. The volume button has the following options and symbols:
Of
Low volume
High volume
2. The music button has the following options and symbols:
Continuous fun music
Continuous soothing melodies
Baby-activated (the music starts when the baby hits one of the
hanging toys)
Cleaning and storage
The Pad and Bassinet are the only machine washable parts. Wash each
one separately in cold water on the gentle cycle and line-dry in the
shade. Do not use bleach. Do not tumble dry. Do not dry clean.
A. Untie the strings.
B. Remove the Pad from the Bassinet by
pulling the safety restraint belts from it.
C. Unsnap the Bassinet Connectors. Push each
set of snaps together and gently lift the
Bassinet Connector.
D. Insert a thin, round-shaped tool
inside each hole of the right
and left frames and remove the
metal base.
E. Slide the Bassinet fabric of the metal base.
All other parts – wipe down with a damp cloth and allow to air dry.
Do not immerse in water.
Remove the batteries for long-term storage or periods of non-use.
And don't forget these safety rules:
Batteries should be replaced by adults only.
Do not mix old and new batteries.
Non-rechargeable batteries are not to be recharged.
Rechargeable batteries are to be removed from the mobile before
being charged.
Rechargeable batteries are only to be charged under adult
supervision.
Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-
cadmium) batteries.
Exhausted batteries are to be removed from the toy.
Do not burn batteries. Dispose of batteries in a safe and appropriate
manner.
Use only batteries of the same or equivalent type as recommended.
Batteries are to be inserted with the correct polarity.
The supply terminals are not to be short-circuited.
4
