Assembly Instructions
M B
LLR16209
High Table Side
Leg Frame
Leg Frame Adjustable Glide
1 PC 2 PCS
D
LLR16208
Adjustable Cross
Bar Set
Cross Bar Set
1 PR
B N
LLR16210/16211
/16236
4-Drawer Cabinet
with Side metal
Adjustable Glide File Clip
Frame
4 PCS 4 PCS
STEP 1
STEP 3
IMPORTANT NOTE:
• Place all laminated parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched.
• Check to make sure that you have all parts and hardware.
• Remove all wrapping materials, including staples and packaging straps before you start to assemble.
• Do not tighten all screws/bolts until pieces are completely assembled.
• Keep all hardware parts out of children's reach.
• It is recommended for 2 persons to complete this assembly.
C
Screw M4.8*22
12 + 2 extra PCS
E F C
U Bracket Screw M8*20 Screw M4.8*22
4 PCS 4 PCS 8 + 2 extra PCS
O P Q
300*16*3mm 96mm Metal Scallop
Metal Bar Shape Handle Side Metal Frame
2 PCS 4 Sets
Rubber hammer

G H
Screw M8*8 Allen Wrench-4#
8 PCS 1 PC
C R
Screw M4.8*22 Screw M4*40
1 PC 6+2 extra PCS 4+2 extra PCS
STEP 2
  


I
T
S
Allen Wrench-5# Metal Flat Plate Screw M5*19
1 PC 1 PC 8 + 2 extra PCS
TWO PEOPLE ARE REQUIRED TO
ASSEMBLE AND MOVE THIS MODEL
Rubber hammer
