! These operating instructions are an integral part of this product.
They contain important information and safety notes, and should
therefore be kept in a safe place at all times. Be sure to pass
them on to the new owner if you ever dispose of the product.
1. S
N
AFETY
OTES
Read the instructions before using the controller
!
Avoid heat build-up
!
Provide unobstructed air circulation round the controller
Do not connect the flight battery with reversed polarity
!
Connecting the battery leads with reversed polarity will
instantly wreck the controller
For this reason:
• red wire to the POSITIVE terminal (+)
• black wire to the NEGATIVE terminal (-)
When soldering or working on the motor or controller
!
Always disconnect the battery (short-circuit / injury hazard)
When testing and running the power system
!
Motor can start in both directions, note stick position when
switching on! Do not run the motor while holding it in your
hand; always secure the model firmly. Check that there is
adequate space for the propeller to rotate. Remove all objects
from the area around the propeller which could be sucked in
or blown away (clothing, paper etc.). Never stand in the
rotational plane of the propeller (injury hazard).
2. S
PECIFICATION
ROXXY BL-Control
Order No.:
max. continuous current:
Pulse frequency:
Battery /
Cell count
Cell count with BEC disabled:
S-BEC voltage:
S-BEC current:
Max. no. of servos ***
Dimensions in mm (approx.):
Weight incl. leads
* MULTIPLEX Nano-S, Tiny-S, HS-55 or HS-81 and similar ones
** HiTEC HS-645MG, HS-5585MG or D954SW servo types
*** If the number of servos in the model exceeds the stated maximum, it is
essential to disable the S-BEC and use a separate receiver battery (
3. S
F
PECIAL
EATURES
The ROXXY 725 S-BEC 4D controller has been specially
developed for use with indoor models, Shockflyers. Therefor he
offers special features:
• Optionally as a normal controller for Shockflyer
or
• Forward and reverse function for the ultimate
3D flying experience (4D flying)
• Particularly easy to set or switchable
• No complicated programming necessary
• No undervoltage cut-off for maximum power in forward and
reverse operation!
Normal operation or as a forward and reverse controller for
backward flying is programmable via the remote control throttle
stick, at power up.
MULTIPLEX Modellsport GmbH & Co.KG • Westliche Gewerbestraße 1 • D-75015 Bretten • www.multiplex-rc.de
Operating Instructions
725 S-BEC 4D
# 1-01171
25 A
(burst 35 A)
41,6 kHz
2...4 S LiPo or
5...12 NiXX
2...4 S LiPo or
5...12 NiXX
5,5 V
max. 2,0 A
(burst 3A)
5 Mikro / Standard*
2 High Torque**
26x12,5x5
9
ROXXY BL-Control 725 S-BEC 4D
• • Start safety system prevents unwanted motor start up when
connecting the battery
• • Engine shutdown in case of massive radio interference or
missing transmitter signal
4. W
IRING
Note: if you wish to use a different connector system for
!
connecting a ROXXY BL-Control S-BEC speed controller to
your motor and / or battery, please note the following infor-
mation:
Soldering requires some care, as the quality of the joints is
crucial to the reliability of the power system:
Use electronic-grade solder for all soldered joints
Parts to be soldered must be hot enough (the solder must
flow), but must not be overheated (damage to components)
If you are unsure, ask a modeller with experience in soldering
to help you
Carefully insulate all solder joints and bare wires (e.g. using
heat-shrink tubing)
Attaching the battery connectors
The battery connectors have to be attached to the two wires (red
= +, black = -). Keep the wires as short as possible. If necessary,
cut the battery leads to the required length. Fit a piece of heat-
shrink sleeve on each wire, and shrink the sleeve over the
soldered joint. Take great care to maintain correct polarity when
soldering the battery connectors to the leads. Reversed polarity
inevitably and invariably wrecks the controller.
Connecting the speed controller to the motor
The motor is connected to the three wires which exit one end of
the controller. Solder sockets to the wires which match the motor
connectors, and insulate each soldered joint with a separate
heat-shrink sleeve. Keep the leads as short as possible.
If you need to reverse the direction of rotation of the motor,
simply swap over two of the three wires leading to the motor.
Connecting the three-core lead (UNI connector system) to
the receiver
Connect the three-core receiver lead (attached to the speed
controller) to the receiver input socket used for motor speed
control:
Pin assignment
Negative pin (−)
Positive pin (+)
Signal (
)
5. U
SING THE UNIT FOR THE FIRST TIME
1.
Commissioning normal function, only forward flying
1.1
Programmable RC
system
set servo travel for
7.).
throttle / motor to
100% in both
directions
1.2
Move transmitter
throttle stick (and trim,
if present) to the motor
OFF position
1.3
Transmitter ON
1.4
Connect a fully-
charged flight battery
2.0
Commissioning with forward & reverse function (4D)
brown
red
orange
⇒ Threeway sequence of tones
⇒ followed by 4th sound
⇒ Controller is ready for use
Seite 3/6
