FOAM INSTALLATION
Shelves must be installed before installing foam.
Your foam kit will cover the inside walls of one side of the cabinet. Install the
foam from the bo om up.
e foam panels have an adhesive coating that is
covered by a removable backing. Before removing the backing, place the foam
in the cabinet as described below to make sure you are using the correct size
foam for each step. For best results, remove the backing by pinching the
backing and the foam together at a corner and then peeling away the backing.
1. Cabinet Side Foam (2)
Start at the bo om of the cabinet. Remove
the foam backing and gage the foam to the
inside bo om and back of the cabinet.
Apply the upper foam panel by gaging the
upper side foam to the top of bo om side
foam and to the back of the cabinet.
2. Cabinet Back Foam (2)
Start with the bo om cabinet back foam.
Remove the foam backing and gage the foam
to the inside bo om of the cabinet and to the
lower side foam. Gage the upper back foam
to the top of the bo om back foam and to
the upper side foam.
3. Cabinet Partition Foam (2)
Start with the bo om cabinet partition foam.
Remove the foam backing and gage the foam
to the inside bo om of the cabinet and to the
lower back foam. Gage the upper partition
foam to the top of bo om partition foam and
to the upper back foam.
Place the foam without the backing on the
bo om of the cabinet
16 1/2"
[419mm]
22"
[559mm]
10 1/4"
[260mm]
22"
[559mm]
11 1/2"
[292mm]
22"
[559mm]
BOW HANGER INSTALLATION
Install bow hangers before mounting the cabinet to the wall.
Assemble the bow hangers to the
cabinet sides or to the center partition
with the screw and washer as shown.
Cabinet Side Locations
To assure that your bows hangs properly inside and outside the cabinet, use
only the mounting hole shown above.
of the cabinet and 2 mounting holes in the center partition. Use these
mounting hole positions to con gure your cabinet as shown below.
NOTE:
e foam lining you installed will cover some of these mounting
holes. Push the screw through the foam to mount the bow hanger.
Center Partition Locations
ere are 2 mounting holes in each side
For the cabinet con guration where there
are shelves on one side, mount one bow
hanger on the center partition in the upper
or lower hole located behind the center of
the partition. Do not use the rst set of holes.
Mount one bow hanger on the inside of the
cabinet on the outside wall as shown in the
cut away image.
For the cabinet con guration where there
will be bows on both sides of the center
partition, mount a bow hanger on each side
of the center partition. Mount one bow
hanger on the inside of both the le and
right side walls of the cabinet.
You can also mount 2 bow hangers on the
outside of the cabinet in the upper front
mounting holes.
Make sure there is room on the outside to
store and access your bows and equipment.
Hang your bows on all the bow hangers
before mounting the cabinet to a wall .
40298-1202
3
18
