SHELVING ASSEMBLY
Interior of the cabinet must be assembled before mounting the
cabinet to a wall.
A er you have reviewed and selected a shelving con guration (see Cabinet
Con gurations) you are ready to assemble the center partition and shelves in
the cabinet. For ease of assembly, do not tighten the nuts and bolts until all the
parts have been assembled.
Shelves on left
1. Center Partition Assembly
Lay the cabinet on its back on a protective surface.
Position the center partition carefully to align the holes on the bo om.
center partition has two possible positions. You should face the front ange
towards the side you want to mount the shelves as shown.
sets of mounting holes. Use the le holes when the shelves are on the right.
Use the right holes when the shelves are on the le .
partition is in the exact center of the cabinet, and that there is proper spacing
for the shelf installation.
Install and tighten the 2 nuts and bolts as shown.
Shelves on right
e
ere are also two
is will ensure that the
2. Top Shelf Assembly
e top shelf has 2 sets of holes for a aching the center partition. Use the set
of holes that will allow the partition to be centered between the 2 holes.
will ensure that there is proper spacing for the shelf installation on both sides.
Position the shelf so the front and side anges point down. Assemble the top
shelf to the center partition and the sides of the cabinet using 6 nuts and bolts.
3. Shelf Assembly
You have the choice of 3 locations for mounting the 2 shelves. You also have
the choice of having the front ange of the shelf to point up or down. Select a
location and assemble each shelf to the center panel and cabinet side using 4
nuts and bolts.
Now tighten all remaining nuts and bolts.
is
2
18
40298-1202
