USING THE BATTERY MAINTAINER CHARGER
See Figure 24.
When storing the pressure washer, connect the battery
maintainer charger to keep the battery fully charged and
ready for use.
NOTE: The battery maintainer charger provided should only
be used with the 12V 4.5Ah/20HR sealed lead acid battery
model RT1245B supplied with this pressure washer.
Plug the battery maintainer charger into a standard
household 120V receptacle. Make sure the household
power supply is 120V, 60 Hz, AC only.
Remove the input cover and connect the battery maintainer
charger to the pressure washer's maintainer input. The
light on the battery maintainer charger will illuminate red
while the battery is charging.
The battery will become slightly warm to the touch while
charging. This is normal and does not indicate a problem.
When battery is fully charged, the red light will turn green.
NOTE: If the light does not illuminate, the battery maintainer
fuse may need to be replaced. Check the fuse and replace
if needed.
Disconnect the battery maintainer charger before operating
the pressure washer. Place the cover over the the pressure
washer's maintainer input when not in use.
CHANGING BATTERY MAINTAINER CHARGER
FUSE
See Figure 25.
NOTICE:
Do not use a higher rated fuse other than the specified
amperage. This could cause damage to the product.
Open the fuse holder and remove the old fuse.
Insert new 7.5 amp fuse and close the fuse holder.
SPARK ARRESTOR
See Figure 26.
WARNING:
Muffler surfaces are very hot during and after operation
of the pressure washer. To avoid serious personal injury,
keep all body parts away from the muffler.
NOTICE:
The spark arrestor on this product has not been evalu-
ated by the USDA Forest Service and cannot be used
on U.S. forest lands. In addition, product users must
comply with Federal, State, and local fire prevention
regulations. Check with appropriate authorities. Refer
to accompanying engine manual for maintenance and
replacement parts.
MAINTENANCE
Inspect the spark arrestor for breaks or holes. Clean or
replace if necessary.
To clean the spark arrestor:
Allow the muffler to cool completely.
Remove the flange nuts securing the muffler cover. Remove
cover and set aside.
Remove the screw securing the spark arrestor in place.
Remove the spark arrestor and gently clean using a wire
brush (not provided).
Replace the spark arrestor and reinstall the screw. Tighten
to secure.
Replace the muffler cover. Reinstall flange nuts and tighten
securely.
STORING THE PRESSURE WASHER
See Figure 27.
NOTE: Regular use of fuel stabilizer and pump protector
will give you better performance of the unit and increase
the life of the pump.
WARNING:
While storing, keep at least 914 mm (3 feet) of clearance
on all sides of this product, including overhead. Allow
a minimum of 30 minutes of "cool down" time before
storage. Heat created by muffler and exhaust gases could
be hot enough to ignite combustible objects.
Store in a dry, covered area where the weather can't damage it.
It is important to store this product in a frost-free area. Always
empty water from all hoses, the pump, and the soap tank
before storing.
Drain the fuel tank completely by running the pressure
washer until the gas runs out. Stored gas can go stale in
30 days.
NOTE: Make sure the water supply is connected and
turned on when allowing the pressure washer engine to
run.
Make sure the engine switch is in the OFF position and
the fuel valve is in the CLOSED position.
Disconnect both the high pressure hose and the garden
hose from the pump.
Empty the pump by pulling on the starter grip and rope
about 6 times. This should remove most of the liquid from
the pump.
NOTICE:
The use of a pump protector is required after each use
and before storing to prevent cold weather and seal
damage during storage. Failure to use pump protector
will void your warranty.
Drain the lubricant and replace with fresh, clean lubricant
as described in Adding/Checking Engine Lubricant in
the Operation section of this manual.
Page 15 — English
