Power Probe FUSE MONITOR Manuel D'utilisation page 8

FUSE MONITOR
Supported Fuse Type
MINI
Cold
Rating
Resistance
2A 55.60mΩ
3A 33.75mΩ
4A 23.48mΩ
5A 17.75mΩ
7.5A 10.85mΩ
10A 7.42mΩ
15A 4.58mΩ
20A 3.21mΩ
25A 2.36mΩ
30A 1.85mΩ
Battery
● Battery Type: 3.7V / 420mAh Li-ion Battery * 1
● Battery Life: 10 hours (Flashlight off)
● Low Battery Voltage: 3.5V
● FUSE MONITOR turns off automatically after no button is
pressed for 10 minutes.
ATC
Cold
Rating
Resistance
1A 176mΩ
2A 53.50mΩ
3A 31.10mΩ
4A 22.80mΩ
5A 17.85mΩ
7.5A 10.91mΩ
10A 7.70mΩ
15A 4.80mΩ
20A 3.38mΩ
25A 2.52mΩ
30A 1.97mΩ
35A 1.61mΩ
40A 1.44mΩ
7
EN
MAXI
Cold
Rating
Resistance
20A 3.10mΩ
25A 2.39mΩ
30A 1.95mΩ
35A 1.71mΩ
40A 1.42mΩ
50A 1.10mΩ
60A 0.89mΩ
70A 0.64mΩ
80A 0.54mΩ
